Outdoor 720 860mhz Vhf Uhf Digital Tv Yagi Antenna F Female Connector 9dbi - China

ELECTRICAL

Model DT-YA720-860-9

Frequency Range 720-860MHz

Gain 9dBi

Beamwidth H: 55°, E: 50°

VSWR ≤1.5

Polarization Vertical o Horizontal

Max power 50W

Nominal Impedance 75Ω

Lightning Protection DC Ground

MECHANICAL

Connector N Female or customized

Antenna Dimension 720mm

Weight 0.5kg

Radome Material Aluminium

Rated Wind Velocity 60m/s

Elements 6
