High Efficiency U Pipe Collector - China
price: check with company for price
High Efficiency Tile Roof Vacuum Tube U Pipe Solar Collector Black Aluminium Alloy Frame Specifications Three-high Solar collector tube 1 - advance technology.
2 - solar vacuum tube 3 - high efficient.
Work principle Evacuated tubes convert solar energy into heat energy, that is transferred to U pipe by an aluminum fin with high solar energy absorption and low heat radiance loss, Liquid (antifreezing liquid or water) in the U pipe heats up, and the U pipe conducts thermal energy to the water inside the storage tank directly (or through internal copper coil), With a testing pressure of 1.2 MPa, Working pressure is 0.6MPa.
Specification of three-high all-glass vacuum heat collection tube: Structure: All-glass double-tube co-axial structure; 1 - Glass material: High borosilicate 3.3 glass.
2 - External pipe diameter and thickness: =470.7mm &=1.6mm;=580.7mm &=1.6mm;=700.7mm &=2.0mm.
3 - Internal pipe diameter and thickness: =370.7mm &=1.6mm;=470.7mm &=1.6mm;=580.7mm &=2.0mm.
4 - Pipe length: 800mm;1200mm;1500mm;1600m m;1800mm;1900mm;2000mm;21 00mm.
5 - Absorptive coating property: Structure: Cu/SS-ALN(H)/SS-ALN(L)/AL N.
Deposition Method: 3 high magnetron sputtering plating.
Absorption than: As=0.93~0.96(AM1.5).
Emission ratio: 0.04~0.06(805).
6 - Vacuum tightness: P50x10-3 (Pa).
7 - Idle sunning property parameters: Y=260~300m2 .
/KW.
8 - Solar irradiation for obtaining a preset water temperature: H4.7MJ/m2 (58) H=3.7~4.2 MJ/m2 H3.7MJ/m2 (47) H=2.9~3.2 MJ/m2 9 - Average heat loss coefficient: ULT=0.4~0.6W/(m2.
).
Thermosyphon In each vacuum tube there is a U pipe with direct flow-through that is connected to the header pipe inside manifold.
This U pipe is seamed in an aluminum heat transfer fin in the interior of vacuum tube that transmits the heat from the interior tube to the U pipe.
Solar radiation permeates the outer glass tube and is captured on the outside of inner glass tube by highly selective sputter layer.
The captured solar radiation is transmitted to flush-contact aluminum shield and then copper pipe filled with heat transfer fluid.
The 360 Aluminum heat transfer fin assures the fastest energy transfer.
- - - - Model No | Solar vacuum tube | Suitable water tank | Loading qty | qty | Tube size | Tube thickness | 20GP | 40GP | 40HQ | PT-U-10 | 10 | 58X1800 | 1.6mm | 85L/100L | 173 | 334 | 421 | PT-U-12 | 12 | 58X1800 | 1.6mm | 100L/120L | 151 | 292 | 367 | PT-U-15 | 15 | 58X1800 | 1.6mm | 125L/150L | 117 | 227 | 286 | PT-U-18 | 18 | 58X1800 | 1.6mm | 150L/180L | 98 | 190 | 239 | PT-U-20 | 20 | 58X1800 | 1.6mm | 166L/200L | 99 | 191 | 241 | PT-U-24 | 24 | 58X1800 | 1.6mm | 200L/240L | 79 | 152 | 192 | PT-U-30 | 30 | 58X1800 | 1.6mm | 250L/300L | 63 | 121 | 153 | PT-U-36 | 36 | 58X1800 | 1.6mm | 300L/360L | 57 | 110 | 139 | - - - - Quality Guarantee 1 - We provide 5years warranty of products and shipment with 1% spare parts 2 - We can send the parts free on condition that there is any breakdown with convincing evidence 1% spare parts include: - Wiper scraper seal - Tube holder - Screws & screw caps Contact We will reply your email or fax within 24hours You can call us at any time if there is any question on our production
Company Contact:
- Phone: 86-135-11388384
- Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China
- Email:
Published date: April 19, 2018
- Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.
As an experienced company, we can provide the perfect solution for Solar Thermal System.
Our products include solar water heater, solar collector and accessories.
