Tiled Roof U Tube Solar Collector - China

Tiled Roof Aluminium Alloy Manifold U Pipe Solar Collector Antifreezing High Temperature Specifications 1 - more efficiency 2 - no water in the tube 3 - high absorption Working principle of U Pipe Solar Collector The U type solar collector are always connected with existing heating supply device.

The selective coating of the evacuated tube converts solar energy into heat energy and transfers heat to metal U tube by the aluminum fin.

The liquid (usually glycol-water antifreeze mixture) in the metal U tube is heater, and conducts the heat energy to the water inside the storage tank through plate exchanger or internal spiral coiler.

Technical Parameters Manifold(interior): red copper Manifold(exterior): aluminum alloy U Pipe: diameter 8mm thickness/ 0.6mm /red copper Aluminum fin: 1600 mm full length Heat insulation layer: Eco-friendly rockwool 50mm Vacuum tube: 58*1800mm SS-CU-AIN/ALN coating Bracket: Aluminum alloy 1800mm 0-50 degree Hail resistance: 25mm Max pressure: 6 bar Anti-freezing: > -35 C Daily efficiency: 55% Advantage: 1) Reliable and efficient twin-glass solar tubes 2) U type copper pipe for rapid heat transfer 3) Integrated package 4) Free maintenance 5) Suitable for mains pressure water 6) Corrosion resistant silver brazed copper header 7) The surface is made of aluminum board 8) Powder coated (black or silver) aluminum casing 9) Stable solar conversion during the day 10) The perfect solar collector for domestic solar water heater systems 11) Ideal for commercial solar water heating applications Parameter Table - - - - Type | Area(M2) | Vacuum tube Qty(pcs) | Length/Width/Height (mm) | G.W. (KG) | 20GP/40GP/40HQ Loading Qty(sets) | PT-C02-10 | 0.991 | 10 | 1660*920*150 | 26.7* | 72/156/176 | PT-C02-15 | 1.492 | 15 | 1660*1270*150 | 38.3 | 52/112/126 | PT-C02-20 | 1.992 | 20 | 1660*1970*150 | 50.6 | 40/86/98 | PT-C02-25 | 2.493 | 25 | 1660*1970*150 | 63.3 | 32/70/80 | PT-C02-30 | 2.993 | 30 | 1660*2320*150 | 75 | 28/58/66 | Vacuum tube size: 58*1800mm | - - - - Remark Manifold Connections(inch): 3/4 Max.

service temperature: 95C Max.

stagnation temperature: 200.3C Flow range recommendation(50-150L/m2 h) Payment term: 1 - T/T 30% Deposit in advance and balance should be paid after receiving the B/L copy.

2 - L/C at sight (if your quantity reaches 5*40 HQ container) 3 - Sample order or LCL: we accept western union and one touch business.

Packing and shipping: MOQ: 20'GP container (Sample is available) Warranty: 10 years guarantee for whole set solar water heater Payment term: 30% deposit by TT, Balance for BL by TT or LC Delivery time: 7 days after confirmed Port of departure: Shanghai or Ningbo Supply ability: 8000 sets per month Package: Standard export cartons

Company Contact:

• Posted By: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD.

• Phone: 86-135-11388384

• Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China

• Email:

• Website: https://www.thermalsolarwaterheater.com

• Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.

  As an experienced company, we can provide the perfect solution for Solar Thermal System.

  Our products include solar water heater, solar collector and accessories.
