Skd1 Mold Steel Bar Optimization Of Key Process Parameters For Spheroidizing Annealing - China

Optimization of Key Process Parameters for Spheroidizing Annealing of SKD1 Mold Steel Bar Precise Control of Temperature Parameters

Heating Rate Control: After cold material is fed into the furnace, slowly heat to 600~650°C at a rate of ≤150°C/h for preheating.

After holding at preheated temperature for 1~2 hours, then heat to the annealing temperature at a rate of ≤100°C/h.

Purpose: To prevent thermal stress cracking of high-carbon, high-chromium steel due to poor thermal conductivity.

Temperature Uniformity Requirements: Temperature difference in the effective working area of ​​the furnace ≤±10°C.

For large steel bars (Φ>100mm), the holding time needs to be extended, calculated at 1.5~2 hours/25mm cross-section.

Reasonable Setting of Time Parameters

The determination of holding time needs to comprehensively consider the following factors: Table Influencing Factors Time Adjustment Strategy

Steel Bar Diameter For every 25mm increase, extend the holding time by 1~1.5 hours.

Charging Amount Extend by 10%~20% when the charging density is high.

Carbide Segregation Extend the isothermal time when there is severe segregation.

Furnace Type Differences Pit-type furnaces reduce heat preservation time by 10% compared to box-type furnaces.
