Iso X153crmov12 Steel Stress Relief Annealing Process - China

ISO X153CrMoV12 steel (corresponding to DIN 1.2379, AISI D2, JIS SKD11) is a high-carbon, high-chromium cold work tool steel.

Its chemical composition includes 1.45-1.60% carbon, 11.0-13.0% chromium, and alloying elements such as molybdenum and vanadium.

This steel is renowned for its excellent wear resistance and high hardness.

It is typically supplied in a softened annealed state (hardness ≤255 HBW), and after quenching and tempering, its hardness can reach HRC 60-62 - During machining, significant residual stress accumulates within the material due to cutting, grinding, or cold working deformation.

If stress-relief annealing is not performed, this stress will be released during subsequent quenching, leading to workpiece deformation, cracking, or dimensional deviations.

Stress-Relief Annealing Process Parameters

Standard Process Specifications

Based on EN ISO 4957 standards and industry best practices, the stress-relief annealing process parameters for ISO X153CrMoV12 steel are as follows: Table

Process Parameters Parameter Range Recommended Value Remarks

Heating Temperature 600-710°C 650-700°C Below Ac1 point to avoid phase transformation

Holding Time 2-4 hours 2 hours/25mm section Ensure heat penetration and full stress release

Cooling Method Furnace cooling or air cooling Furnace cooling to 500°C followed by air cooling Control the cooling rate to prevent new stress generation

Applicable Conditions After rough machining, before quenching - Must be completed before final hardening Key Temperature Range Analysis:

600-650°C (West Yorkshire Steel Recommendation): Suitable for stress relief after general machining

660-710°C (Virat Steels Data): For heavy-duty cutting or complex-shaped workpieces

~680°C (Arascelik Technical Specification): Optimal temperature balancing efficiency and effect
