W6mo5cr4v2 Heat Treatment Guide Annealing Hardening Tempering For M2 Hss Users - China

W6Mo5Cr4V2 heat treatment practice decides whether your M2 type high speed steel tools reach the famous 63-65 HRC working hardness and long service life.

This grade, equivalent to AISI M2, DIN 1.3343 and JIS SKH51, responds very well to a correctly controlled treatment cycle.

1 - Soft Annealing for W6Mo5Cr4V2

- Heat slowly to 850-870 C, hold 2-4 hours depending on section size

- Cool in furnace at maximum 20-30 C per hour down to about 600 C, then air cool

- Delivered hardness: maximum 255 HB, perfect for machining 2 - Stress Relieving

- After heavy rough machining, heat to 600-650 C and hold about 2 hours

- Slow cooling reduces distortion risk during hardening 3 - Hardening W6Mo5Cr4V2

- First preheat: 650 C to equalize core and surface

- Second preheat: 850 C

- Austenitize at 1210-1230 C, soaking about 20-25 seconds per mm of thickness

- Quench in oil, hot salt bath at 500-550 C, or vacuum furnace with high pressure nitrogen

- As quenched hardness: about 63-65 HRC with some retained austenite 4 - Tempering

- Begin tempering when the part cools to about 50-70 C

- Triple tempering at 540-560 C, holding 1-2 hours per cycle

- Each cycle transforms retained austenite and precipitates secondary hardening carbides

- Final working hardness: 63-65 HRC

- Optional cryogenic treatment between tempering cycles improves dimensional stability and wear life Why the W6Mo5Cr4V2 heat treatment schedule matters:

- Too low an austenitizing temperature leaves undissolved carbides and lower hardness

- Too high a temperature coarsens the grain and causes brittleness

- Skipping tempering cycles leaves soft retained austenite that fails in service Following this W6Mo5Cr4V2 heat treatment guide gives the best balance of red hardness up to 600 C, wear resistance and toughness for drills, milling cutters, saw blades and cold work dies.
