Order For X210cr12 Ledeburitic Steel Hot Rolling Process - China

X210Cr12 Ledeburitic steel is a typical high-carbon, high-chromium ledeburitic cold-work die steel.

The primary challenges in its hot rolling process lie in the fragmentation of coarse eutectic carbides present in the as-cast structure, as well as the material's poor high-temperature plasticity and susceptibility to cracking.

Consequently, the process requires slow preheating, precise temperature zone control, heavy reductions, frequent turning, and controlled slow cooling to produce hot-rolled billets or plates with a uniform microstructure and free from cracks.

Key Points for Hot Rolling (Specific to Ledeburitic Steel)

1 - Rolling Principles

- **Multiple Passes, Small Reductions, Large Total Deformation**

- Single-pass reduction rate: **10–15%** (≤20%)

- Total compression ratio: **≥4–6: 1** (to effectively fracture eutectic carbides)

- **Bidirectional Rolling, Frequent Turning**

- Alternating longitudinal and transverse passes; forging/rolling on all four sides to **eliminate anisotropy and homogenize carbides**

- **Rapid Pace, Minimal Holding Time**

- Inter-pass interval: ≤30s; temperature drop: <30°C per pass

2 - Typical Rolling Process (Ingot → Plate/Bar)

1 - **Ingot Inspection: ** Removal of surface defects, shrinkage cavities, and cracks

2 - **Staged Heating: ** Three-stage preheating (400°C / 700°C / 1100°C) followed by soaking

3 - **Blooming (Rough Rolling)**

- Temperature: 1080–1050°C

- Passes: 6–10 passes; **total reduction rate: 50–70%**

- Objective: **To fracture coarse eutectic carbides**

4 - **Finish Rolling**

- Temperature: 1000–900°C

- Passes: 4–6 passes; **single-pass reduction: 8–12%**

- Objective: Dimensional accuracy, surface quality, and uniform microstructure

5 - **Post-Rolling Treatment (Critical Step)**

- **Immediate Transfer to Furnace for Slow Cooling: ** **Hold at 650–700°C for 4–8 hours; furnace cool to <500°C, then air cool**

- **Strictly Prohibited: ** Stack cooling or open-air cooling (risk of **stress cracking and precipitation of network carbides**).

For X210Cr12 Ledeburitic Steel, the key to successful hot rolling lies in "slow heating, precise temperature control, multiple passes with small deformations, bidirectional rolling with high total compression, and post-rolling slow cooling followed by timely annealing.

" The core objective is to fracture coarse eutectic carbides and prevent thermal stress and low-temperature cracking.
