3a Stainless Steel Sanitary Tubing 20 Length With Mechanical Polished - China
price: check with company for price
1'' OD 16 Gauge (0.065'') TP304 Polished 3A Stainless Steel Sanitary Tubing, Welded, 20' Length Features: GLOBAL STANDARDS: Our tubes conform to ASME-BPE, 3A, ISO-SMS & BS 4825 standards with ASTM-A 270 specifications.
QUALITY RAW MATERIAL: We source our stainless steel strips from POSCO.
A company of global repute, trusted worldwide.
TRACEABILITY: All tubes are marked with heat number on its surface.
A well organized documentation plan ensures every tube can be tracked back to every stage of manufacturing.
EX-STOCK AVAILABILITY: We have ex-stock availability of almost all sizes grades and surface finishes.
Option to order even small quantities as required.
CERTIFICATIONS & ACCREDITATION: We manufacture tube for the global market.
We are certified/ accredited with ISO 9001: 2008, 3A, PED 91/23/EC, AD 2000 MERKBLATT-W0, .
Descriptions: - - - - Item Code: | SPW-A270-304-0100-065-MP- 3A | Tube OD: | 1'' | Wall: | 16 Gauge (0.065'') | Length: | 20' | OD Tolerance: | +/-0.005'' / +/-0.13MM | WT Tolerance: | +/-10% | Length Tolerance: | +1/8'' / +3.18MM | Material: | TP304 | Standard: | 3A / ASTM A270 / A270M | Finish: | 20Ra ID / 32Ra OD | Polish: | Mechanical Polished | Type: | Welded | Certification: | 3A - Food / Dairy Grade | Mill Test Certificate: | EN10204 3.1 | Packing: | Sleeved, Ends Capped, Wooden Boxed | - - - - Chemical Compositions: - - - - Elements | 304 (wt%) | C / Max.
| 0.08 | Mn / Max | 2.00 | P / Max | 0.045 | S / Max | 0.030 | Si / Max | 1.00 | Ni | 8.00 - 11.00 | Cr | 18.00 - 20.00 | Mo | N/A | Fe | Bal.
| Cu | N/A | N | N/A | - - - - Mechanical Properties: - - - - Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) | Hardness (HRB) | 304 | 515 | 205 | 35 | 90 | - - - - Quality Assurance: We are one of the leading suppliers for tubes in the Food & Beverages industry.
Our tubes are backed with years of our experience working with the beverages & breweries.
We understand the requirement of the F&B industry better.
The quality of the inner surface finish of the tube is very critical, when it comes to the transfer of aerated drinks, Fruit juices, Beer, wine etc.
Be it the process lines, CIP / SIP lines, we have the right tubes that fit.
Our in-house and proprietary process of electropolishing ensures a very high internal surface finish of the highest quality (Ra <0.38 m).
Applications: Our stainless steel sanitary tubings are applicable to a wide range of manufacturing industries: 1 - Food & Beverage 2 - Dairy 3 - Wine & Brewery 4 - Cosmetic
Company Contact:
- Posted By: Spezilla Tube Co., Ltd.
- Phone: 86-21-57701837
- Address: No.18 Baosheng Road, Songjiang District, Shanghai, China, Shanghai , Shanghai , China
- Email:
Published date: May 17, 2018
- Business Description: Spezilla is an ISO9001 & 3A manufacturer and global supplier of stainless steel sanitary tubings, fittings and valves.
Our products are manufactured using high grade raw materials and in compliance with international quality norms for the Food, Dairy, Beverage, Breweries, Cosmetic, Biotech and Pharma
