Glass Lined Steel Waste Water Treatment Tank Volume Can Be Expanded - China

Center Enamel Co., ltd dedicated in vitreous enamel products 1989, our main product is glass fused to steel bolted tanks and stainless steel bolted tanks.

We are not only the first glass fused to steel tanks manufacturer in China, but also the first one to produce double -sides enamel hot-rolled steel in China.

We are the largest and the most professional enamel bolted tank supplier in China.

We have more than 30 years experience of enamel production, company covers an area of 80, 000 square meters.

Our company has the most advanced production line, and already passed, and product and design can reach AWWA D103-09 standard, OSHA and meet European standards.

We are the only enterprise that can produce AA grade (acid-proof and alkali- proof ) enameled sheet now.

According to customers’ different operating requirements, we can customize various products.

The production of glass fused to steel sheet Enamel – coating is a traditional anti – corrosion technology .

Used the technology, the steel is beautiful and glazed outside, but strong and anti – corrosion inside .

Coating on the special titanium steel plate, the enameled bolted tank has been successfully applied in varieties of industries, agricultural sewage, urban sewage and other wastewater treatment systems and biogas projects .

Glass Lined Steel Waste Water Treatment Tank Specifications Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coatings internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds Quality Control: * Raw materials testing in the factory: ingredient analysis, impurities test ; * Recipe finalized small samples test : enamel fluidity test, chromatic difference analysis, enamel burning experiment, acid and alkali resistance testing, glossy, adhesion etc * Middle stage products test : amplification experiment simulated environment； * Destructive testing, detection, impact test, sparks test, sliced electric microscope analysis .

About Center Enamel About Center Enamel Center Enamel Co., Ltd is not only the first and most experienced Glass-Fused-to-Steel Tanks manufacturer in China, but also the leading storage tanks manufacturer in Asia.

Center Enamel storage tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc.

international standards.

CEC storage tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.

The superior product quality and prompt service gain us worldwide recognition.
