Center Enamel Glass Fused To Steel Waste Water Storage Tanks For Wastewater Treatment Projects - China

Glass-Fused-to-Steel (Glass-Lined-Steel) is a unique tank finish.

Glass fused to steel tanks provide steel strength with corrosion resistant glass, inside and outside.

Glass-Fused-to-Steel (GFS) is not strictly a coating, but a combination of the two materials that provides excellent life protection in almost all water and wastewater applications.

It has also been variously described as glass lined steel (GLS), glass coated steel (GCS) or glass enamel steel, but it is nevertheless described as the ultimate solution for tanks and silos.

Center Enamel is internationally recognized as the world's leading manufacturer of Glass-Fused-to-Steel tanks.

All inner surfaces are 100% inspected by the factory to further improve product quality.

Glass-Fused-to-Steel is able to provide many years of trouble free service in harsh environments.

This system has been proven over many decades on thousands of installations, and is supported by International Standards which cover the design and finish requirements.

Glass-Fused-To-Steel Wastewater Storage Tanks Specififcations Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coatings internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds About Center Enamel Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.

Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc.

international standards.

CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.

The superior product quality and prompt service gain us worldwide recognition.
