20a Ac Current Clamp Gfuve Q8a2 8mm Hole Split Core Ct Transformer Probe Sensor - China

price: 138.00 Dollar US$

20a Ac Current Clamp Gfuve Q8a2 8mm Hole Split Core Ct Transformer Probe Sensor

Products Photos Catalog 20a Current Clamp Photos Catalog

The model Q8A2 permalloy core ac current clamp ct with high accuracy up to 0.1% has been designed for use with energy meter tester, multimeters, recorders, power analyzers, safety testers etc.

It has low phase shift for power measurement, greatly suitable for electric energy meter calibrator and oscilloscope.

This Q8A2 clamp ct can convert 0 - 10A AC current to 0 - 10mA AC current with real shape, max 20A measurement, but with harmonic measurement function.

It is suitable for leakage current measurement in the field.

Electrical parameters

Ratio: 1000: 1, 2000: 1 or 2500: 1 (customized)

Accuracy class: 0.1 %, 0.2%

Primary current: 0 - 5A AC, 0 - 10A AC, 0 - 20A AC

Secondary current: 0 - 10mA AC or 0 - 100mV AC (customized)

Max.

Cont.

Input current: 6A, 12A, 24A

Load capacity: ≤20Ω, Standard 4Ω

Over voltage category: CAT III 600V

Output signal (AC current): From 0 to 10mA AC at nominal input current

Output signal (AC voltage): From 0 to 100mV AC at nominal input current

Signal ratio: 1mA/A, 1mV/A, 10mV/A, 100mV/A

Frequency range: 10Hz-200KHz

Dielectric strength: 3KV 50Hz/60Hz at 1 minute

Temperature range: -20°C to +55°C

Output: 2.5 meter cable with D01 connector

Max.

voltage not insulated conductors: 720 V

Standard: EN 61010-1, EN 61010-2-032, EN 61010-2-031

IEC60044-1, & IEC61869-2, 600V CAT III

Installation: Clamp type

Output mode: Lead output (2.5m)

Connector: BNC, 4mm banana, Audio plug, customized

Mechanical parameters

Dimensions (L x W x H) (mm): 45x158x25

Weight (g): 250

Holding wire diameter (mm): φ8

Max.

jaw opening (mm): 8

Jaw color: Black

Material: PC+ABS+Polycarbonate, UL94 V0


Company Contact:


  • Phone: 18901232181

  • Address: Oriental HuaRui A No. 150 Guanzhuang Road Chaoyang District Beijing, 100024, China, BEIJING , China

  • Email: Email


Published date: February 2, 2024

  • Business Description: Beijing GFUVE Electronics Co., Ltd. was established in 2005 - It combined science, industry and trade together as one high-tech enterprise.
