Anti Collision Marine Rubber Fender Length 0 5 9 0m Less Reverse Impact - China

Used For Anti-Collision With Pneumatic Marine Yokohama Rubber Fender Advantages of ARD floatingrubber fender:

* Absorb more energy, less reverse impact on the ships

* More flexible, easy installation

* Durable, practical and economical

* Good quality have been checked by many buyers

* Optional tire and chain, can provide chain with hot galvanizing or stainless steel(304, 312, 316)

* Optional end fittings for the better suitable of applications Application of ARD rubber fender:

ARD pneumatic rubber fender has widespread application as following:

* Ship to ship, ship to wharf

* Oil tankers, container vessels

* Luxury yachts, ocean platforms

* Larges shipyards

* Fender system

* Military ports, warship

* Larger under water foundations of bridges, etc Technical performance of marinerubber fender - - - -

Specification

DXL(m) | 0.05Mpa(Initial pressure 0.05Mpa) | (Initial pressure 0.08Mpa) | Weight(kg) | Reaction force(KN) | GEA

(KJ) | Weight

(kg) | Reaction force(KN) | GEA

(KJ) | 0.5X1.0 | 25 | 674 | 6 | 25 | 85 | 8 | 0.6X1.0 | 32 | 74 | 8 | 32 | 98 | 11 | 0.7X1.5 | 50 | 137 | 17 | 50 | 180 | 24 | 1.0X1.5 | 80 | 182 | 32 | 80 | 239 | 45 | 1.0X2.0 | 100 | 257 | 45 | 125 | 338 | 63 | 1.2X2.0 | 120 | 297 | 63 | 165 | 390 | 88 | 1.35X2.5 | 165 | 427 | 102 | 226 | 561 | 142 | 1.5X3.0 | 315 | 579 | 153 | 370 | 761 | 214 | 1.7X3.0 | 405 | 639 | 191 | 436 | 840 | 287 | 2.0X3.5 | 590 | 875 | 308 | 632 | 1150 | 430 | 2.5X4.0 | 1050 | 1381 | 663 | 1110 | 1815 | 925 | 2.5X5.5 | 1333 | 2019 | 943 | 1410 | 2653 | 1317 | 3.0X5.0 | 1880 | 2000 | 1050 | 2155 | 2709 | 1571 | 3.0X6.0 | 2160 | 2488 | 1312 | 2470 | 3292 | 1888 | 3.3X4.5 | 2020 | 1884 | 1175 | 2300 | 2476 | 1640 | 3.3X6.0 | 2300 | 2783 | 1675 | 2600 | 3652 | 2338 | 3.3X6.5 | 2700 | 3015 | 1814 | 3080 | 3961 | 2532 | 3.3X10.6 | 4403 | 5257 | 3067 | 5020 | 6907 | 4281 | 4.5X9.0 | 6554 | 5747 | 4752 | 7470 | 7551 | 6633 | 4.5X12 | 8739 | 7984 | 6473 | 9960 | 10490 | 9037 | Note: The weight is the fender body weight(without tires and chain), with weight error of 10% and counterforce error of 10% | - - - - Storage of ARD rubber fender * When not using for a long time, wash the surface of the fender, dry up and fill in sufficient right amount of compressed air to lay them in a cool.

dry and well-ventilated place.

* The storage place of pneumatic rubber fender should be far away from hear source * Try to keep fender away from acid, alkali, grease and organic solvents * When not applying the fenders, the pneumatic rubber fender cant be piled up and heavy items cant be piled on the fender
