Solid Aluminum Curtain Wall Panels - China

Solid Aluminum Curtain Wall Panels Manufacturer | Ruiyike

Description: Custom 3003/5005 solid aluminum curtain wall panels in 1.5–3.0 mm thickness with PVDF or powder coating.

Submit drawings for project pricing.

Keywords: Solid Aluminum Curtain Wall Panels Manufacturer | Ruiyike

Aluminum single-panel curtain wall is a metal exterior wall decoration system made of high-quality aluminum alloy as the base material, which is formed by bending, welding and spraying.

What is an Aluminum Single-Panel Curtain Wall?

An aluminum single-panel curtain wall is a mainstream metal curtain wall system for modern buildings.

Used for exterior facade projects of commercial buildings, office buildings, hotels, stadiums, etc.

It uses high-strength aluminum alloy panels as the main body, manufactured through CNC machining, bending, and fluorocarbon spraying processes, and is installed using a dedicated keel structure.

It combines decorative appeal, safety, durability, and environmental friendliness, and can achieve various appearance effects such as flat, curved, irregular shapes, carvings, and perforations, making it the preferred material for high-end building facades.

Ruiyike manufactures custom solid aluminum curtain wall panels for opaque curtain wall areas, ventilated facades, entrances, canopies, soffits, parapets and column cladding.

Unlike aluminum composite material, each panel is fabricated from a single aluminum alloy sheet without a bonded core.

The panels can be CNC cut, folded, welded and reinforced according to approved shop drawings.

Panel dimensions, edge returns, stiffener layout, fixing details and surface finish can be coordinated with the facade contractor’s installation system.

Explore our complete range of aluminum curtain wall and facade panels for commercial building projects.

Solid Aluminum Facade Panel Specifications

Specification Available Options

Panel Construction Single solid aluminum alloy sheet with no composite core

Aluminum Alloy 3003 or 5005 series; alloy and temper confirmed according to forming and finish requirements

Panel Thickness 1.5 mm, 2.0 mm, 2.5 mm and 3.0 mm

Panel Size 1220 × 2440 mm standard sheet format; custom fabricated sizes up to 1500 × 6000 mm subject to drawing review

Surface Finish PVDF coating, powder coating, anodized, brushed, wood-look and stone-look finishes

Color RAL, Pantone or approved physical sample matching

Fabrication CNC cutting and bending, welded returns, reinforcing ribs, corner brackets and custom openings

Applications Commercial facades, office towers, hotels, transportation hubs, public buildings and facade renovation

Designed for Facade Contractors and Bulk Project Supply

♦ Drawing-based fabrication: Panels are produced according to the approved elevation, panel schedule and fabrication drawings rather than supplied as generic stock sheets.

♦ Controlled flatness: Folded edges and project-specific reinforcing ribs help control panel movement and visible surface distortion.

♦ Consistent exterior finish: PVDF coating is available for exposed facades requiring weather resistance and stable long-term appearance.

Color and gloss can be confirmed by sample before production.

♦ Installation-ready delivery: Panel-number labelling, protective film and export packing can be coordinated with the installation sequence.

Core Advantages of Aluminum Single-Panel Curtain Walls

Highly customizable shapes, offering great design freedom.

It can be processed into any shape, including flat, single-curved, double-curved, irregular shapes, corners, and column cladding, easily adapting to complex building exteriors and achieving various styles such as modern, minimalist, and artistic.

Lightweight and high-strength, structurally safe and stable.

Aluminum alloy is lightweight and high-strength, significantly reducing building load; it has strong resistance to wind pressure, earthquakes, and deformation, and will not deform or crack over long-term use, ensuring high safety.

Fluorocarbon Coating: Weather-resistant and with an exceptionally long service life.

The surface is treated with fluorocarbon coating (PVDF), making it resistant to UV rays, acid rain, salt spray, and corrosion.

It will not fade, chalk, or rust for over 20 years of outdoor use.

Environmentally Friendly and Fireproof, Meeting High Building Standards: The material is Class A fireproof, formaldehyde-free, recyclable, and environmentally friendly; non-flammable and non-explosive, suitable for public buildings such as schools, hospitals, shopping malls, and office buildings.

Easy Installation and Low Maintenance Costs: Modular dry-hanging installation ensures fast construction and smooth joints; the panel surface is easy to clean and does not easily accumulate dust, simplifying maintenance and significantly reducing future renovation costs.
