55inch Lcd Video Wall - China

LCD Panel Model 55inch 4k uhd lcd video wall did

Resolution 1920×1080(H×V)

Pixel Pitch 0.63×0.63(mm)

Brightness 450(cd/ m )

Contrast Ratio 3000: 1

Response Time 6ms

Display Color 16.7M

Viewing Angle 178°(H) / 178°(V)

Image Aspect Ratio 16: 9

Compensation Technology LTI, CTI

Motion Compensation Technology AUTO MOVE

Filter 3D combing filter, Digital noise reduction

Video Formats PAL, NTSC

Signal Source Composite Video Input CVBS(BNC) ×1;

Composite Video Output CVBS(BNC) ×1 ;

Digital Signal Input HDMI×1; 1920x1080@60Hz Backwards compatible

Computer Signal Input VGA(DB-15) ×1;1920x1080@60Hz Backwards compatible

Digital Signal Input DVI(DVI-I)×1;1080P(1920� �1080) Backwards compatible

Built-in Controller Computer Centralized Control Interface RS232

Function Signals combine and display arbitrarily Automatic Temperature Control Work automatically according to the set temperature and actual temperature of the machine to control fan operation

System Image Signal Gain A more stable and correct image control

Operation Mode Computer centralized control

Bus Control I C

MTBF 60000 hs

Power Supply Voltage 100~240V

Power Consumption 185W

Sructure Frame Size Upper side: 11mm; lower side: 11mm; left side: 11mm; right: 11mm

Size of product 1215.5mm×686.3mm×140.5m m

Display Area 1209mm×680mm

Installation Position 564×200(mm)

Material of Shell Metal

Installation Standard cabinets, custom cabinets

Weight G.W. About 31Kg

N.W. About 22Kg

Environment Storage Temperature -20°C~65°C

Working Temperature 0°C~55°C

Working Humidity 10%~90%

Quality Quality Assurance CCC, FCC, UL, CE, RoHS

Environmental Protection Standard All components and packaging materials are in line with international environmental standards
