Security Arms Durable Galvanized Powder Coating Metal Barrier Gate - China

NAME: Barrier Gate MOTOR MATERIAL: Die-casting Aluminum

COLOR: Blue, Orange And White APPLICATION: Over-sized Traffic Flow Area

CABINET: 2mm Zinc Plated Steel USAGE: Road Traffic Safety

WARRANTY: 1 Year FEATURE: High Durable

SURFACE TREATMENT: Powder Coating

Security gate arms Durable Galvanized/Powder Coating Metal Barrier Gate Technical Data Model 102-11 102-13 102-16 102-33 102-26 102-33 102-36 102-46 102-56

Running time 1 sec 3 sec 6 sec 3 sec 6 sec 3 sec 6 sec 6 sec 6 sec

Boom type Straight 90° folding 180° folding 2 fencing 3 fencing

Max Boom length 3 m 4.5m 6m 3m 5m 3m 5m 4.5m 4m

Boom dimension (WxH)mm 45*80 45*100

Boom weight 3 kg 4.5kg 6 kg 6.5 kg 8 kg 9 kg 11 kg 7 kg 7.5 kg

Voltage 220V±10%, 110V±10%

Frequency 50/60HZ

Motor voltage 220V

Power 80W

Working Temperature -35℃~+75℃

Protection grade IP44 Functions & Features 1) Manual realease 2) Machine core with compression spring, effectively avoids the accidents caused by spring breaking; 3) Die-casting aluminum alloy motor, precision and good at thermal radiating; 4) Motor cooling fan, solving the problem of heat-protection; 5) Double safety limitswitches (photoelectricity limit switch/motor memory sensor);

6) Reversing on obstacle; 7) Auto-closing; 8) Support the In frared Photocell for anti-bumping function(optional); 9) Support the external and internal Vehicle Loop Detector; 10) Traffic light interface; 11) Wire Control ( switch signal) / remote control (418 HZ/433 HZ ); 12) RS485 Communication module (optional).
