Protective Clothing Flame Spread Test Machine Bs En Iso 15025 - China

Introduction:

Protective clothing flame spread tester is according to ISO 15025 to design and produce .

It can test the flame spread state under the smallflame .

It is used to simulate the protective clothing is at the risk of ignition to assume the flame spreadperformance .

It is also suitable forthe fabricmaterial or other similar functional use of combustiblematerials .

Standard

BS EN ISO 15025: 2016

Model: FTech- ISO15025

Features:

1 - The combustion chamber is made of stainless steel; corrosion-resistant; Dimension: 1200mm X 600mmx 1200mm.

2 - All sample holder is made of stainless steel which is corrosion resistance.

3 - The Humboldt burner is imported from the USA, the flame is more stable; Horizontal flame height 25mm ± 2mm; vertical 40mm ± 2mm; nozzle opening 0.19mm.

4 - The time is automatically recorded, automatic storage; timer accuracy 0.1s.

5 - PLC with touch screen control system, more intelligent; automatically record test data, automatic storage;

6 - Imported pressure gauge and regulating valve, the gas pressure is more stable;

7 - Imports needle valve, control the flame height precisely;

8 - Equipped with two sets of sample holders for surface combustion and bottom combustion.

9 - Automatic ignition, automatically turns off;

10 - Equipped with a flame height ruler;

11 - Pulse high voltage electronic automatic ignition.

12 - Timing button with the PLC automatically record, storage burning time.

13 - There is no need to hold a stopwatch for timing; the test time system automatically records and generates the test report;

14 - The test time can be set on the touch screen.

Meet the requirements of various test standards;

15 - The test program of surface combustion and bottom combustion can be switched on the touch screen.
