Lifepo4 Fire Extinguishing System - China

Main Description The size of lithium-ion battery boxes produced by different manufacturers varies.

After installing lithium-ion batteries, the internal volume of the lithium-ion battery box is insufficient, making it very difficult to install the Lifepo4 Fire extinguishing system.

To meet the narrow lithium battery box application scenario, we invented an ultra-thin aerosol-based Lifepo4 fire extinguishing system.

Ultra-thin fire extinguishers are more suitable for narrow lithium battery boxes, allowing installation workers to better install energy fire extinguishing systems.

Technical Data Sheet The following are the specific technical parameters of this new invention: Special Name: Ultra-Thin Lifepo4 Fire Extinguishing System.

Model Number: QRR0.012G/S/SA-F.

Generator Material: Painted steel.

Main Chemical Compound: Aerosol agent, with the main oxidant of strontium nitrate and potassium nitrate.

Compound Weight: 0.012 kilograms.

Gross Weight: 0.1 kilograms.

Discharging Time: 3 seconds.

Dimension of Product (mm): 68(L)*84(W)*8(D/H).

Covering Area: 0.12 cubic meters.

Compound Concentration: 100 grams per cubic meter.

Main Application Scenarios: lithium battery boxes for renewable energy, meter boxes for the power industry.

Activation Method of Fire Extinguishing Agent: 3-24 volt power start, and 175 ℃ thermal start.

Activation Current Parameter: 500 to 700 mA.

Safety Current Parameters: less than 150mA.

Suitable Fire Classes: A, B, C, F.

Pressure signal feedback form: N/O or N/C optional.

Operating Temperature: -40℃ to +95℃.

Life-cycle of the Product: 10 Years.

This product can be paired with other aerosol models for energy storage cabinets, energy storage containers, battery vehicles, and charging facilities in the new energy field.

Among them, the ordinary 12g lithium battery fire extinguisher has the same fire extinguishing ability as this Ultra-Thin Lifepo4 Fire Extinguishing System.

In short, it has a significant effect on extinguishing fires in new energy facilities and equipment.
