6000w Dc12 24v Ac220v Solar Converter Power Inverter Qw P6000 - China

Applicable for: ( Solar/Wind/Home System )

1 - Travel set equipment

2 - Industrial equipment

3 - Office equipment

4 - Kitchen equipment

5 - Household electrical equipment

6 - Power tools

Technical Parameter:

Input: Input voltage: DC12V/DC24V/DC48V

Working Voltage: DC10V-15V/DC20V-30V/DC40V -60V

Input current: 500A/ 250A/125A

Standby input power: <50W

Start no load current: <4A

Output: Rated power: 6000W

Peak power: 12000W

Efficiency: >85%

Output voltage: AC110V/220V+/-5%

Output frequency: 50/60Hz+/-1%

Output current: 54A/27A

Output waveform: Pure Sine Wave

Protection: Reverse connection protection: fuses burne

Low input voltage alarm: 10.1V+/-0.3V; 20.5V+/-0.3V; 42V+/-1V

Low input voltage protection: 10.7+/-0.3V; 20.1+/-0.3V; 40+/-2V

High Input voltage protecton: 15V+/-1V; 30V+/-1V; 60V+/-2V

High temperature protection: ≥70ºC

Over load protection: >6200W

Short circuit protection

Digital display Indicator:

Inverter woking: green light on

Inverter problem: no 110V/220v display

Protection alarm:

Low input voltage alarm: buzzer

Low input voltage protection: no display, buzzer and inverter stop working

High input voltage protection: no output voltage display, have input display, inverter stop working.

Over load protection: voltage drop to 55V-140V

Abnormal temperature: no AC display, buzzer and stop working.

Environment: High temperature protectioin: ≥70ºC

Working Temperature: -10ºC~40ºC

Cooling mode: Intelligent Temperature control Fan

Package included: 1* QW-P6000(500*170*135mm/10 kg)

1* battery clamp

1* spare part

1* english user manual

1* standard packing box

Warranty: 12 months

Quality stanstard: CE, RoHS
