3000w Dc To Ac Pure Sine Wave Power Inverter Qw P3000 - China

Technical Parameter:

Input:

Input voltage: DC12V/DC24V/DC48V

Working Voltage: DC10V-15V/DC20V-30V/ DC40V-60V

Input current: 250A/125A/62.5A

Standby input power: <25W

Start no load current: <2A

Output:

Rated power: 3000W

Peak power: 6000W

Efficiency: >85%

Output voltage: AC110V/220V+/-5%

Output frequency: 50/60Hz+/-1%

Output current: 13.6A

Output waveform: Pure Sine Wave

Protection:

Reverse connection protection: fuses burne

Low input voltage alarm: 10.7V+/-0.3V; 20.5V+/-0.3V; 42V+/-1V

Low input voltage protection: 10.1+/-0.3V; 20.1+/-0.3V; 40+/-2V

High Input voltage protecton: 15V+/-1V; 30V+/-1V; 60V+/-2V

High temperature protection: ≥70ºC

Over load protection: >3200W

Short circuit protection

Digital display Indicator:

Inverter woking: green light on

Inverter problem: no 110v/220v display

Protection alarm:

Low input voltage alarm: buzzer

Low input voltage protection: no display, buzzer and inverter stop working

High input voltage protection: no output voltage display, have input display, inverter stop working.

Over load protection: voltage drop to 55V-140V

Abnormal temperature: no AC display, buzzer and stop working.

Environment:

High temperature protectioin: ≥70ºC

Working Temperature: -10ºC~40ºC

Cooling mode: Intelligent Temperature control Fan

Package included:

1* QW-P3000B

1* battery clamp

1* spare part

1* english user manual

1* standard packing box

Warranty: 12 months

Quality stanstard: CE, RoHS
