High Efficiency Flat Plate Solar Thermal Collector - China
price: check with company for price
High Efficiency Germany Blue Film Flat Plate Solar Collector Laser Welding Aluminum Frame Specifications environmental flat plate solar collector 1 - high efficiency 2 - long life flat plate collector 3 - OEM 4 - SGS SRCC CE ISO2000 Environmental flat plate solar collector What is Features of our environmental flat plate solar collector ? Red copper inner tube with average compressive property (working pressure is 0.2Mpa) Safe and cl factory price flat plate solar energy collector ean inner tube is applicable for unpressurized open loop system The selective absorption coating is using anodizing and electric pigmentation The absorptivity is94% and the emissivity is 18% The strong thermal stability coating can bear high temperature as 185C The strong weather ability of the oxidized aluminum fin has long life over 15 years Aluminum fin costs less than copper one What is Specifications of our environmental flat plate solar collector ? - - - - Type | PT-A | Cover | Dimension LxWxH | 2000 x 1000 x 80 | Cover No.
| 1 | Gross Area(m2) | 2 sq.m. | Cover Material | tempered glass | Aperture Area(m2) | 1.85 sq.m. | Cover Thickness | 4mm | Absorber Area(m2) | 1.83 sq.m. | Cover Transmission | over 89% | Absorptivity | 94% | Weight | About 32kg | Emissivity | 18% | Cover No.
| 1 | Max.
Working Pressure | 0.2MPa | Life Span | 15 years | Absorber | Thermal Insulation | Fin Dimension | 1850x 122x 0.65 | Density | 32kg per cubic meters | Material | Copper-aluminum Compound | Insulation Material | Fibre Glass | Surface Treatment | Anode Oxidation | Insulation Thickness | back: 40mm side: 20 mm | Construction Type | Tube and fin | Casing | Header Material | Copper | Frame | 6063 Aluminum Alloy | Header tube size | 22 0.7mm 2pcs | Frame Color | Champagne | Riser Material | Copper coil pipe line | Frame Thickness | 1mm | Riser tuber size | 12 0.7mm 8pcs | Back Plate | Aluminum Plate (1mm ) | | | Sealing Gasket | EPDM | - - - - What is Applications of our environmental flat plate solar collector? 1 - Domestic: Flats, Bungalows and Apartments.
2 - Commercial: Hotels, Hospitals, Hostels and Dormitories.
3 - Industrial: Process Industries, Preheating boiler feed water.
Trade Terms: Payment: T/T, L/C Delivery: Within 10 working days Why choose us? 1 - We are Chinese Leading environmental flat plate solar collector Manufacturer; 2 - Alibaba environmental flat plate solar collector Top 10 Golden Supplier; 3 - Inspected by the inspection of TUV&DINCERTCO; 4 - 100% QC Inspection before Shipping; 5 - Best Quality & Professional service with Competitive price.
Packaging & Shipping Packaging Details: Export strong corrugated carton.
Delivery Detail: Within 7 - 10 days for container order quantity upon confirmed invoice or sales contract.
Warranty: 10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.
Company Contact:
- Phone: 86-135-11388384
- Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China
- Email:
Published date: April 19, 2018
- Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.
As an experienced company, we can provide the perfect solution for Solar Thermal System.
Our products include solar water heater, solar collector and accessories.
