200l Solar Thermal Hot Water Heating System - China

200L Compact Non Pressurized Vacuum Tube Thermal Solar Water Heater Stainless Steel Bracket Description: It must be installed on the top, such as roof, to get enough hot water flow pressure by the gravity.

With the assistant tank or water tower, could be feed water automatic.

An simple controller can operate the electric or show temperature and water level inside the water tank.

Specification: 1 - Inner tank: SUS304-2B food grade stainless steel, 0.4mm 2 - Outer tank: Color Steel with anti-corrosion layer.

3 - Heat insulation layer: Imported PU(thickness: 55mm).

4 - Vacuum tube: 58mm*1800, Three target, 1.6mm 5 - Frame(Stand): Galvanized steel with Paint, 1.5mm.

25 degree optional.

6 - Working Temp: minus 20 to 260 Celsius degrees 7 - Working pressure: less than 0.5Mpa - - - - Vacuum tube | 58/1800-10/20/30 | Water tank capacity | 100 - 300 Liters | Inner tank | food grade stainless steel, SUS304-2B | Outer tank | painted color steel | Bracket | galvanized steel | Installation | Other | Circulation Type | Direct Loop | Color | cool white | With Accessories or Not | Yes | Voltage | 110-220V | Current Type | AC | Pressure | Unpressurized | Body Materials | Glass, Others, Polyester, Stainless Steel | Frequency | 50HZ-60HZ | Type | Non Pressure | Connection | Direct-Plug | Heating System | Other | Certification | CE | - - - - Description of Integrated Low Pressure Solar Water Heater: - - - - Parameters | Heat delivery method: | Direct-plug vacuum tube | Diameter & material of inner tank: | 360mm, food grade stainless steel | Diameter & material of outer tank: | 470mm, stainless steel | Heat preservation: | 55mm polyurethane layer | Bracket: | Stainless steel | Specification | Model | Dia.

of tube(mm) | Length of tube(mm) | No.

(pcs) | Water Tank capability(L) | Loading 20/40/40HQ (pcs) | 58/1800/12-100 | 58 | 1800 | 12 | 100L | 54/108/132 | 58/1800/15-125 | 58 | 1800 | 15 | 125L | 45/89/108 | 58/1800/18-150 | 58 | 1800 | 18 | 150L | 38/77/93 | 58/1800/20-165 | 58 | 1800 | 20 | 165L | 35/70/85 | 58/1800/24-200 | 58 | 1800 | 24 | 200L | 30/60/73 | 58/1800/30-250 | 58 | 1800 | 30 | 250L | 24/49/59 | - - - - - - - - Payment Terms | L/C, T/T, D/A, D/P, Western Union, Money Order, Paypal, Others | Minimum Order | 1 set | Lead Time / Delivery Time | 15 Day | Sample Available | YES | Delivery Details | within 15 workdays, based on quantity.

| FOB Port | Shanghai, Ningbo | Loading | FOB/CNF/CIF/DDP/DDU, deliver by air or by sea.

| Packing | 1) samples allowed, although we suggest container order to provide the tubes from breaking.

2) wooden case for sample delivery, while cartons for bulk order delivery.

| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Middle East & South Asia, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East | - - - -
