Sale Of Xy 180 Hydraulic Drill For Geological Core Drilling And Physical Investigation - China

1 - Applications of XY-180 hydraulic core drilling rig

The XY-180 hydraulic core drilling rig is designed on the basis of the XY-1A hydraulic core drilling rig.

It is a low speed and high torque portable drilling machine with oil pressure.

This drill rig is suitable for engineering geological survey of railway, hydropower, traffic, drilling holes for small holes and blasting holes, bridge, dam foundation and other buildings, geological core drilling and physical investigation, a small water well drilled.

3 - Parameters of XY-180 hydraulic core drilling rig

Borehole diameter(mm) 75/91/110/130/150/300

Drilling depth(m) 180/150/120/90/70/30

Maximum opening diameter(mm) 375

Drill pipe diameter(mm) 42/50

Spindle stroke(mm) 450 Spindle speed (r/min) 71/142/310/620

Upgrading ability (KN) 15

Diameter of steel wire(mm) 12

Type gear pump

Model YBC-12/80

Displacement(ml/r) 8

Rated pressure (MPa) 8

Rated speed (r/m) 1500

Power supply ZS1115 diesel engine and 15kw motor

Company Contact:

• Posted By: Shandong Master Machinery Group Co.,Ltd.

• Phone: 18865479502

• Address: No.47,Jinyu Road,Jining City,Shandong Province,China, jining , China , China

• Email:

• Website: http://www.sdjujiang.com

• Business Description: Shandong Master Machinery Group Co., Ltd. is located in Jining city, Shandong Province , which is known as "The hometown of Confucius, formal state" reputation .

  Company east to “ Oriental holy city”of qufu, west to “hero”of liangshan, “qilu graceful” weishan lake in the south, "wuyue exclusive" Tarzan in the north, The martial arts are prosperous, and the people are geeky.

  convenient transportation like Jining airport, beijing-shanghai high-speed railway, lunan high-speed railway, beijing-taiwan expressway, zhanlan high-speed crisscross, , communication developed.

  Shandong Master Machinery Group Co., Ltd. as parent company and head office hold the spirit of "delivering the spirit of craftsman and the quality of the great craftsman" for a long time , Pragmatic development will strengthen our progress.

  Nowadays, it has developed into a collectivized enterprise integrating r&d design, production processing and marketing.

  The group company mainly provides solutions for engineering and mine construction.

  With high quality products, good service and honest reputation, our company has established a solid material supply relationship with several universities, research institutes, design institutes and reconnaissance institutes.

  And stand out from a large number of national key project construction projects , The market performance is among the best in the industry.

  The group company actively responds to the national "One Belt And One Road" policy to go abroad.

  Drilling rig products are now sold to many countries in Europe, central Asia, southeast Asia and Africa.

  Our company's independent brand "HuaxiaMaster" has become a well-known brand for customers.

  It is a pleasure to have friends coming from afar.

  We warmly welcome friends from all walks of life to visit our company and work together to create a better tomorrow.
