Kqz 180d Pneumatic Electric Dth Drilling Rig - China

1 - Brief introductions of KQZ-180D pneumatic-electric DTH drilling rig

KQZ-180D pneumatic-electric DTH drilling rig is suitable for drilling and geothermal drilling.

It has many advantages, such as large diameter, deep drilling, fast footage, flexible movement and wide application area.

2 - Specifications of KQZ-180D pneumatic-electric DTH drilling rig

KQZ-180D

Borehole diameter mm 100-219

Borehole depth m 150

Drilling angle ° 45-90

One-time feed stroke mm 1500

Motor power kw 7.5

Rotating speed of drilling tools rpm 0-78

Air pressure mpa 0.8-2.1

Air consumption l/min 13-21

Weight kg 600
