Huaxiamaster Sale Full Hydraulic Pneumatic Well Drilling Rig Fy 200 Crawler Drill - China

1 - The applications of FY200 crawler pneumatic water well drilling rig

·drilling with large diameter

·deep drilling footage ·civil engineering drilling

·geothermal drilling

·fast, flexible and efficient.

2 - The specifications of FY200 crawler pneumatic water well drilling rig Model FY200

Aperture mm 140-325

Drilling depth m 200

Feed stroke mm 3000

Travel speed km/h 2.5

Grade ability max.

30°

Gross weight t 4.6

Dimension mm 3800*1600*2450

Rising height from ground mm 250

Wind pressure mpa 1.7-3.0

Air consumption m³/min 17-35

Engine power kw 65

Rotary speed rpm 50-70

Rotation torque n.

m 5000-6500
