Fy600 Pneumatic Water Well Drilling Rig - China

Keywords: pneumatic rock drill, pneumatic press, crawler drilling rig, drilling machine water well, drilling rig water we, water well drilling rig, water well drilling machine, dth drilling machine, dth drilling rig, power hammer, borehole water well drilling rig, borehole drilling machine, water borehole drill, dth drilling rig, dth drilling machine

1 - The applications of FY600 crawler type gasoline engine drilling rig

civil engineering drilling

geothermal drilling

drilling with large diameter and deep drilling footage

fast, flexible and efficient.

2 - The specifications of FY600 crawler type gasoline enigne drilling rig Model FY600

Gross weight T 12

Dimension mm 5400*2100*2850

Aperture mm 140-350

Drilling depth m 600

Feed stroke mm 6600

Travel speed km/h 2.5

Grade ability max.

30°

Rising height from ground mm 250

Wind pressure mpa 1.7-3.5

Air consumption m³/min 17-35

Engine power kw 115

Rotation speed rpm 45-110

Rotation torque n.

m 8500-10050
