Haag Streit Type Slit Lamp Biomicroscope - India

This is an Ophthalmic Instrument, used in the treatment of eye diseases like cataract, myopia and other.

Our slit lamps are precession engineered and provide accurate performance.

BINOCULAR MICROSCOPE

Type : Stereoscopic Microscope Eye Pieces : 10x

Objective : 1x, 1.6x

Total Magnification : 10x, 16x

Diameter of Visual Field : 18mm, 14.5mm, 9mm ILLUMINATION

Slit Projection Magnification : 2/3x

Slit Width : Continuous from 12mm to 0mm (at 10mm slit becomes a circle)

Slit Length : Continuous from 12mm to 1mm Or Aperture settings at 9, 8, 5, 3, 2, 1 and 0.2mm dia.

Slit Angle : 0deg.

to 180deg.

with horizontal Scanning capability

Slit Inclination : 0, 5deg., 10deg., 15deg.

and 20deg.

steps.

Filters : Blue, Red Free, ND, Heat-Absorbing No Filter

Lamp : 6V, 20W Halogen Lamp BASE Longitudinal Movement : 95mm

Lateral Movement : 105mm

Fine Base Movement : 15mm

(with joystick)

Vertical Movement : 32mm CHIN REST

Vertical Movement : 82mm

Fixation Target : Luminous Target

Red LED POWER

Input (primary) : AC 220V / 110V

Frequency : 50/60Hz

Output (secondary) : Main Bulb 2.4v, 6.0v for Brightness levels

Power Consumption : 26V A DIMENSIONS & WEIGHT

Table Model : 560 x 407mm

Unit Model : 375 x 335mm

Weight : 21kg STANDARD ACCESSORIES

Dust Cover, Replacing Lamp for illumination unit
