Conveyer Belt Manufacturer - China

Heat-Resistant Conveyor Belt

Notes:

conveyer belt Manufacturer: Hengguang Conveying Machinery

Temperature categorized in 4 models.

T1=100 °CT2=125 °CT3=150 °C T4=180 °CT5 above 180 °C

Fabric type Fabric structure Fabric type Fabric thickness Cover rubber thickness Width Length warp weft Upper Lower EP EP EP EP-100 0.75 1.5-8 0-4.5 400-2500 <=300 EP-150 0.80 EP-200 0.90 500-2500 EP-250 1.15 EP-300 1.25 EP-400 1.45 800-2500 EP-500 1.55 We could offer belt with cover grade in accordance to International standard such as DIN 22102, RMA, AS 1332, SABS 1173/2000, IS 1891, BS 490, JIS K 6322, etc.

Standards Cover Rubber Adhesion Tensile Strength Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply

DIN 22102 Mpa % mm3 N/mm

(≤1.5mm) N/mm

(>1.5mm) N/mm

DIN 22102-Z 15 350 250 3.5 4.5 5

DIN 22102-W 18 400 90 3.5 4.5 5

DIN 22102-Y 20 400 150 3.5 4.5 5

DIN 22102-X 25 450 120 3.5 4.5 5 Standards Cover Rubber Adhesion Tensile StrengTD Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply

AS 1332 Mpa % mm3 N/mm

(≤1.9mm) N/mm

(>1.9mm) N/mm

AS 1332-N17 17 400 200 4 4.8 6

AS 1332-M24 24 450 125 4 4.8 6
