High Speed Single Screw Double Die Heads Film Blowing Machine - China

High Speed Single Screw Double Die Heads Film Blowing Machine

Feature and Advantage

Feature and Advantage: high yield, energy saving, stable, low noise, labor saving, less waste, the film is bright, smooth, feel good

The single screw double die heads film blowing machine provides a good solution for economic but good quality film.

Suitable for general packaging products such as T-shirt bags, rolling bags and many others.

suitable for both HDPE and LDPE film.

In-line printer can be added for logo printing.

The specially designed blown film extruder has good ability for melting and mixing material with master-batch /additives.

High precision die head and cooling air ring provides good film thickness control.

A percentage of recycled material and Calcium carbonate can also be used in the mixture.

Single screw film blowing machine, compact model is popular for starters who look to start the film production business with an economic but reliable machine.

The filming machine model is extremely compact, easy to install, user-friendly and productive for film and bag makers.

It is also widely used by industrial leaders who produce bags in large quantity.

We are Plastic Film Blowing Machine Supplier.

Technology Parameter

Model No.

LF-2H-55 LF-2H-65

Suitable Material LDPE/HDPE LDPE/HDPE

Screw Quantity(pc) 1 1

Die Head Quantity (pc) 2 2

Screw Diameter(mm) 55 65

Max Screw Speed(r/min) 80 80

Traction Shaft Length(mm) 650 650

Max Film Width (mm) 570+14x2 570+14x2

Film Thickness(mm) 0.01-0.1 0.01-0.1

Max Extrusion(kg/hr) 50-60 70-80

Ratio of Length to Diameter(mm) 31: 1 32: 1

Die head diameter 200 250

Extruder Power(kw) 15 22

Traction Motor Power(kw) 2.2 2.2

Heating Device Power(kw) 14.7 23.7

Winder Motor Power(kw) 2.2 2.2

CNC Accuracy 1000g/+1.5g 1000g/+1.5g

Max winding diameter(mm) 1000 1000

Over Dimension(mm) 6600x2700x5370 6600x2700x5370

Total Weight(kg) 3050 3320
