Fully Automatic Online Surface Defect Detection Equipment Bqj D4100 - China

Fully automatic online surface defect detection equipment BQJ-D4100 Purpose: Take all-round photography of rods and wires, bar steel, square steel, rebar, etc.

in a red-hot state, generate complete surface images, analyze and classify identified defects, and provide intuitive visual feedback on the surface quality of rolled products.

Establish a connection based on the collected defect samples and manually labeled fault causes, thereby effectively guiding process adjustments and greatly reducing the generation of waste products.

measured object varieties: rods and wires, rebar, square steel, flat steel;

Application technology: high-speed and high-temperature environment image acquisition technology, automated detection technology, machine intelligence deep learning technology;

Model and technical parameters: V/51000 (V is rolling speed)

At 10m/s: 0.2mm

At 50m/s: 0.4 mm

At 100m/s: 2mm

Minimum lateral defect (mm): 0.045

Minimum depth defect (mm): 0.25

The standard configuration of the entire set of equipment: image acquisition vehicle, terminal control cabinet, cooling unit, air compressor, and auxiliary facilities;

Adaptable rolling speed: ≤120m/s

Adaptable rolling temperature: ≤1200℃ A Surface Inspection System is a technology used to detect and analyze defects or irregularities on the surfaces of various materials.

These systems are essential in quality control processes across multiple industries, such as manufacturing, automotive, electronics, and pharmaceuticals.

Company Contact:

• Posted By: TIANJIN EASTDRAGON PHOTOELECTRICITY CO.,LTD

• Phone: 022 23783384

• Address: K1-4, No.6 HaiTai development 6th road, green industry base, Huayuan industrial zone, Tianjin , Tianjin , China

• Email:

• Website: https://www.measurementon-line.com/

• Business Description: Eastloong Measurement & Control Technology Co.,Ltd. is a professional company to provide the overall measurement scheme for the long steel rolling production line.

  It was founded in 2004 and is located in the beautiful Tianjin High tech Industrial Zone, a green industry base called the "National Software Industrial Park".

  It is composed of optical measurement experts and professional technical talents in optics, machinery, electronics, software, computer, and other fields.

  It is a specialized company that integrates research and development, production, sales, installation, and after-sales service.

  The first domestic photoelectric camera diameter gauge (in 2000), the first laser scanning swing diameter gauge (in 2018), the first rotary diameter gauge (in 2021), the first surface defect detector (in 2022) , and the first rebar measurement instrument(in 2023) were all born in Eastloong.

  The company takes research and development as the leader and quality as the guarantee, with over one hundred patents and software copyrights.

  For many years, Eastloong has been innovating and developing in the field of steel rolling measurement with a focused spirit and enterprising attitude, and has been highly praised by customers.

  Now more than 600 gauges have been installed the steel rolling line in such as Baosteel, Ansteel, Hebei steel, Jianlong group, Shougang steel, Tata steel, JFE, Valin steel ,Shandong steel,etc.

  in many countries.

  Eastloong will still focus on steel rolling measurement ,provide the best service for global steel enterprises.
