Manual Operation Cast Steel Gate Valve Ansi 150lb Bolted Bonnet For Chemical Plants - China
price: check with company for price
Manual Operation Bolted Bonnet Cast Steel ANSI 150LB Wedge Gate Valve For Chemical Plants What is Gate Valve? The distinct feature of a gate valve is the sealing surfaces between the gate and seats are planar, so gate valves are often used when a straight-line flow of fluid and minimum restriction is desired.
The gate faces can be parallel, but are most commonly wedge-shaped.
Applications Petro-Chemical, oil and gas, mining, power and general services Specifications ANSI 150 Cast Steel, OS&Y- ASME B16.34 & API 600 Features Flanged ANSI 150# OS&Y Bolted Bonnet Full Bore Flexible Wedge Construction Body Materials: Cast Steel- ASTM 150# Seat Ring: 2Cr13 Stem: 2Cr13 Disc: 2Cr13 + STL Available Options Sizes in 1/2" to 1" ANSI 150 also available on request ANSI 300 and 600 also available in gate, globe and check valves Material List - - - - No.
| Parts Name | Material | 1 | Body | ASTM A216 Gr.
WCB | 2 | Seat Ring | ASTM A105+13Cr | 3 | Wedge | ASTM A216 Gr.
WCB+13Cr | 4 | Stem | ASTM A182 F6a | 5 | Gasket | 304SS Jackted Graphite | 6 | Stud | ASTM A193 Gr.
B7 | 7 | Nut | ASTM A194 Gr.
2H | 8 | Bonnet | ASTM A216 Gr.
WCB | 9 | Back Seat | ASTM A 276 410 | 10 | Packing | Graphite | 11 | Pin | C.S. | 12 | Gland Bolt | ASTM A 193 Gr.
B7 | 13 | Gland Nut | ASTM A194 Gr.
2H | 14 | Bushing | ASTM A276 410 | 15 | Gland | ASTM A 216 Gr.
WCB | 16 | Stem Nut | Aluminum Bronze | 17 | Bushing | C.S. | 18 | Handwheel | Malleable Iron | 19 | H.W. Lock Nut | C.S. | 20 | Lubricator | Assembly | - - - - NOTE: Customer material is also available.
Company Contact:
- Posted By: TEKO Industry Co., Limited
- Phone: 86-20-84646289
- Address: Xinqiao Industrial Zone, Shiji County, Shiqiao, Panyu Disctrict, Guangzhou, China, Guangzhou , Guangdong , China
- Email:
Published date: April 25, 2018
- Business Description: TEKO Industry Co., Limited, established in 2010, is a rapidly growing industry products manufacturer in China.
Throughout 8 years of development, we have been now becoming the major valve supply in industries of petroleum, chemical plant, power station, mining, metallurgy, waste water treatment, etc.
