20mm Dia Polished Infrared Lenses Plano Convex Lens With Silicon Optical Glass - China

price: check with company for price

Optical 20mm Dia Polished Infrared Lenses Plano-Convex Lens with Silicon Diameter 20mm Polished Infrared Lens Specifications: - - - - Diameter (mm) | 20 | Diameter Tolerance (mm) | +0/-0.1 | Clear Aperture (%) | 90 | Focal Length Tolerance (%) | 2 | Effective Focal Length EFL (mm) | 63.5 | Effective Focal Length EFL @ 1.55m (mm) | 62.22 | Effective Focal Length EFL @ 2.94m (mm) | 63.36 | Effective Focal Length EFL @ 4.0m (mm) | 63.5 | Effective Focal Length EFL @ 5.0m (mm) | 63.65 | Back Focal Length BFL (mm) @ DWL | 63.56 | Radius R1(mm) | 154.17 | Edge Thickness ET (mm) | 2.0 | Center Thickness CT (mm) | 2.5 | Center Thickness Tolerance (mm) | 0.2 | Surface Accuracy | 1 (Specified @ 633nm) | Surface Quality | 80 - 50 | Bevel | Protective bevel as needed | Substrate | Silicon (Si) | Focal Length Specification Wavelength (nm) | 4000 | Coating | Uncoated | Numerical Aperture NA | 0.2 | Wavelength Range (m) | 1.2 - 7.0 | Type | Plano-Convex Lens | RoHS | Compliant | - - - - Description: IR Lenses are used to collect, focus, or collimate light in the near-infrared, short-wave infrared, mid-wave infrared, or long-wave infrared spectra. IR Lenses are optical lenses that use specific substrates or anti-reflection coatings to maximize performance for applications operating above 700nm including thermal imaging, FLIR, or spectroscopy. The infrared spectrum refers to 700 16000nm wavelengths. When divided into smaller spectra, NIR refers to 700 900nm, SWIR is 900 2300nm, MWIR is 3000 5000nm, and LWIR includes 8000 12000nm wavelengths. GIAI Optics offers a large variety of IR Lenses including singlet lenses, achromatic lenses, aspheric lenses, or focusing objectives for high performance across a large portion of the infrared spectrum. IR Achromatic Lenses are ideal for use in a variety of industrial, life sciences, or defense applications including FTIR spectroscopy or for use with tunable QCL lasers. Zinc Selenide IR Aspheric Lenses feature diffraction limited designs that are ideal for focusing the output of CO2lasers. Additional substrates include germanium, sapphire, silicon, zinc selenide, or zinc sulfide. Anti-reflection coating options include VIS-NIR, NIR I, NIR II, Telecom-NIR, or SWIR. Competitive Advantage: diameter 20mm polished infrared lens, competitive price, good quality, delivery on time, providing perfect after-sales service, to provide customers with professional customized products of parameter. We will supply you with best solution. Why us? 1Service time:24 hours waiting for you. 2.Fast Response: 2 hours within our worktime, 12 hours get off work. 3.Good Service: Wecan supply you from design, measure to coating one stop service. 4. MOQ: NoMOQrequirement, youcansetyourorderfreely. 5. After-salesservice: Ifbadquality, wewillrefund. HowtoOrder ? Step 1. Sendtheinquiryatthebottom oftheproduct. Step 2. We will response or quote you within 24 hours. Step 3. Place order through email, fax directly.

Company Contact:

  • Phone: 86-755-89936779

  • Address: F2,block C,Shen Chang Gang Industry Park, Shenzhen, Guangdong, China

  • Email: Email

Published date: February 27, 2018 -

  • Business Description: Giai photonics Co., Ltd is a leading supplier of optics and precision optical components, designing and manufacturing a wide array of optical filters, multi-element lenses, lens coatings.We do this with skilled technicians, expert engineers, and modern optical fabrication equipment, the latest metrology.
