Laboratory Flotation Machine Phosphorus Beneficiation Bf Type - China

Laboratory Flotation Machine Phosphorus Beneficiation BF Type Phosphorus separate Flotation Machine For phosphorus processing : This BF type flotation machine belongs to mechanical stirring self-suction type flotation machine, it is mainly used for sorting the slime below 0.5mm; it also effectively separates iron ore, phosphorus, lead, zinc ore hydrochloric acid, nickel and molybdenum, ferrous metal and nonmetallic minerals.

Flotation Machine is widely used in non-ferrous metal, ferrous metal and so on rough sizing, selection and counter-flotationwork How flotation machine works? When gold, lead ore, copper ore flotation machine works, slurry is inhaled from the bottom of the trough to the space between impellers.

Meanwhile, the low pressure air send by fan is sent to this area through the air distributor in the hollow shaft.

After sufficient mixing, the slurry is pushed out by the impeller, and then goes to the whole trough.

Characteristics of BF flotation Machine: 1 - The impeller consists of closed double section cones, which can produce strong down-circulation; 2 - Big air inlet amount, low energy consumption; 3 - Each trough has the function of air suction, ore pulp suction and flotation, it can make a flotation circuit itself, with no auxiliary equipments.

The horizontal configuration makes it easy to change process; 4 - Rational ore pulp circulation reduces coarse sand sediment; 5 - There are automatic and electric control devices of ore pulp level, which makes easy adjustment.

Technical parameters: - - - -

Model | Effective volume (m3) | Inside dimensions(LWH)(m) | Air suction amount (m3/m min) | Power (KW) | Motor model | Processing capacity (m3/min) | BF-0.37 | 0.7 | 0.740.740.75 | 0.9-1.05 | 0.5 | Y90L-4 | 470 | BF-0.65 | 0.65 | 0.850.950.90 | 0.9-1.10 | 3.0 | Y132S-6 | 932 | BF-1.2 | 1.2 | 1.051.151.10 | 1.0-1.10 | 5.5 4.0 | Y132M2-6 Y132M1-6 | 1370 | BF-2.0 | 2.0 | 1.401.451.12 | 1.0-1.10 | 7.5 | Y160M-6 | 1750 | BF-2.8 | 2.8 | 1.651.651.15 | 0.9-1.10 | 11 | Y180L-8 | 2130 | BF-4.0 | 4.0 | 1.92.01.2 | 0.9-1.10 | 15 | Y200L-8 | 2585 | BF-6.0 | 6.0 | 2.22.351.3 | 0.9-1.10 | 18.5 | Y225S-8 | 3300 | BF-8.0 | 8.0 | 2.252.851.4 | 0.9-1.10 | 22 30 | Y225M-8 Y250M-8 | 4130 | BF-10 | 10 | 2.252.851.7 | 0.9-1.10 | 22 30 | Y225M-8 Y250M-8 | 4660 | BF-16 | 16 | 2.853.81.7 | 0.9-1.10 | 37 45 | Y280S-8 Y280M-8 | 8320 | BF-20 | 20 | 2.853.82.0 | 0.9-1.10 | 37 45 | Y280S-8 Y280M-8 | 8670 | BF-24 | 24 | 3.154.152.0 | 0.9-1.10 | 45 | Y280M-8 | 8970 | - - - -
