Textile Rubbing Color Fastness Tester - Chinaprice: 1.00 Dollar US$
Textile rubbing color fastness tester "Textile friction color fastness tester" detailed introduction
Electric friction dyeing tester is mainly used to test the color fastness of colored fabrics, coatings, printing and dyeing products, the specimen is fixed at one end of the machine body, so that the friction head wrapped with white cotton fabric is in contact with the specimen, the reciprocal movement 10 times, remove the white cotton fabric and rating chart card for comparison, assess the fabric staining color fastness.
Meet the standards of jis-l0801, 0823, 0849, 1006, 1084, k6328, p8136 Application industry.
Applicable to the footwear industry, garment industry, bags and handbags industry, scientific research laboratories; commodity inspection and arbitration, technical supervision departments, etc.
to test the performance of leather products Technical parameters.
Test piece: 22×3cm White cotton cloth: 5 × 5cm Rubbing speed: 30cpm Abrasion hammer load: 200g Auxiliary load: 300g Abrasion hammer size: 45*50mm White cotton stained area: approx.
1cm2 Rubbing distance: 100mm Number of friction sets: 6 sets Counter: electronic 6 digits Volume: 56×55×34cm Weight: 57kg Power supply: AC220 50HZ Test standard.
The staining of white cotton cloth for friction is judged according to the provisions of JIS L 0801 (determination of dyeing fastness).
According to the test results are divided into the following judgments.
A excellent: wet cloth test in the white fine cloth does not leave color.
B Fair: The color is left on the white cloth after the wet test, but no color is left on the white cloth after the dry test.
C Bad: The color is left on the white cloth after the dry cloth test.
Color fastness to rubbing by Crockmeter More about testing instrument: Qinsun Instruments Co., Ltd
