Micro Motion Cng050 Coriolis Flow Meter - China

Micro Motion CNG050 Coriolis Flow Meter Introduction

Single-meter CNG flow meters meet the challenges of measuring compressed natural gas for custody transfer in light- and heavy-duty vehicle dispensers while reducing fill time with higher flow rate capability.

Specifications

Gas Accuracy / Repeatability

±0.50% of batch ( ±0.25% of rate) Line Size

1/2” – 3/4” (DN15 – DN20) Pressure Range

5000 psig (345 barg) Temperature Range

-40 to 257 F ( - 40 to 125 C) Electronics (soft)

Expansive I/O options including mA, Frequency, Discrete Input/Output, HART, Modbus, Ethernet/IP, FOUNDATION Fieldbus Turndown

10: 01 Features

Satisfy needs for light- and heavy-duty vehicle dispensers with a purpose-built, single-meter solution

Use with most fluids with available 316L stainless steel construction

Choose from a wide range of transmitter options, including direct-connect, to accommodate dispenser design requirements

Broad range of meter approvals and certifications, including; CSA (Class 1 Div 1 groups C and D, Class 1 Div 2 groups A, B, C and D, Class II Div 1 groups E, F and G), ATEX, NEPSI, IECEx, Ingress Protection 66/67, and NAMUR

Save time with a compact design with no moving parts, requiring no special mounting or flow conditioning

Rely on custody-transfer-approved certification Common models

CNG050S239NQBMAZZZ CNG050S239NABMAZZZ CNG050S239NCBMAZZZ CNG050S239NWBMAZZZ CNG050S239NDBMAZZZ CNG050S290NQBMAZZZ CNG050S290NABMAZZZ CNG050S290NCBMAZZZ CNG050S290NWBMAZZZ CNG050S290NDBMAZZZ CNG050S291NQBMAZZZ CNG050S291NABMAZZZ CNG050S291NCBMAZZZ CNG050S291NWBMAZZZ CNG050S291NDBMAZZZ
