Hand Held Ultrasonic Flow Meter - China

Model: CSL1

Description: CSL1 Hand-held Ultrasonic Flow Meter Introduction:

1 - Applicable for measurement of single and uniform liquid’s flow and heat, which the liquid can be conducted by ultrasonic.

2 - Non-touch measurement type and large measuring range.

It has no influence from system pressure and bad environment because of no unfixed machinery part.

3 - Be applied successfully in water, pure water, sea water, waste water, chemical liquid, river water, fuel oil measurement.

4 - Applicable for refrigeration, heating, heat exchanger, refrigerator, boiler fields.

Technology parameters: 1 - Measuring precision: flow ± 1%, quantity of heat ± 2%.

2 - Pipe caliber: 15mm~6000mm

3 - Flow velocity: 0~32m/s; linearity: 0.5%; repeatability: 0.2%.

4 - Pipe materials: steel, stainless steel, cast iron, PVC, copper, aluminum.

5 - Measuring object: water, sea water, polluted water, acid and alkali liquid, alcohol, beer, oil (The liquid is single and uniform and can be conducted by ultrasonic).

6 - Display: 4×8(Chinese) or 4×16(English) dot-matrix backlight LCD display; Size: 71×39mm

7 - Language: can choose 3 kinds of Languages among Chinese, English, Italian, French, Turkish and Spanish.

8 - Button: 16+2 buttons.

9 - Communication interface: RS232

10 - Communication agreements: Modbus, M-bus, Fuji extended agreement.

11 - Signal input/output: OCT output, temperature measurement.

12 - Data record: built-in 32Mbit storage and SD card.

Capacity up to 2G(optional).

13 - Power adapter: AC90~260V input; DC6V output; Power: 6W.

14 - Battery: Ni-MH battery, 1.2v, 3 batteries; Capacity: 2000 mAH; Charge time: 8 hours; Working time: 12 hours.

15 - External materials: ABS

16 - Dimensions: 200×93×33mm

17 - Weight: 390g Features:

1 - High precision: precision ± 1%, linearity 0.5%.

2 - Small volume (200×93×33mm), light weight (0.4kg).

3 - Putting magnetic sensor to external wall of pipe can achieve non-touch measurement.

4 - Large range: Can measure DN15~6000 pipe flow by configuring different sensors.

5 - Power: built-in high capacity Ni-MH rechargeable battery.

Continuous working time: 12 hours.

6 - Large LCD screen: can display accumulated flow, instant flow, flow velocity and working status at the same time.

7 - Data recorder: built-in 32Mbit recorder; external SD card (512MB~2G).
