Gas Turbine Flowmeter - China

Vortex flow meter is based on Carmen vortex principle, which adopts piezoelectric crystal as testig components.

It is a new kind of stress detecting vortex flow meter.

It has the advantages of wide rangerate, high accuracy, low pressure loss, good medium generality, pulse signal output proportional to flow, convenient to connect with computer etc.

The detector probe of sensor and the vortex generating body are installed separately, and the high temperature resistant piezoelectric crystal doesn’t contact with medium, so the instrument is of simple structure, good generality and high stability.

Vortex flow meter sensor cn be used to detect and measure the flow of all kinds of gas, fluid and steam.

I can also be used to match with our company’s flow totalizer.

It also can match with computers and sensors of temperature, pressure, or density to composehigh accuracy mass flow or heat flow detecting and measuring system.

FEATURE

◆ High accuracy, up to ±1.5%R, ±1.0%R;

◆ Sensitive response, good repeatability, short-term repeatability can reach 0.05%~0.2%.

It is the preferred flow meter in trade settlement；

◆ Can detect the temperature, pressure and flow of the measured gas.

High-reliability gas precision measuring instrument capable of automatic flow tracking and compensation;

◆ It can be equipped with oil injection pump to protect the impeller and prolong the service life of the Flowmeter

MEASURING MEDIUM

1 - Mostly used for metering control of natural gas

2 - It can also be used for biogas, liquefied petroleum gas, coal gas, nitrogen, hydrogen and other gases.

It is widely used in gas metering and gas pressure regulating stations, transmission and distribution pipeline networks, and urban natural gas metering in various industries such as petroleum, chemical industry, electric power, and industrial boilers.

FLOW RANGE TABLE

Gas turbine m3/h

DN25 4-40

DN40 10-100

DN50 16-160

DN65 25-250

DN80 40-400

DN100 65-650

DN125 100-1000

DN150 160-1600

DN200 250-2500

DN250 400-4000

DN300 600-6500 Yuhan Electronic flowmeters offer unrivalled value in terms of installation and cost of ownership and serve a diverse market, providing flow measurement solutions that meet the needs of each customer's application.

Listening to our customers' needs and innovating unique solutions is our speciality.

To find out more, please click on a product from the list.
