Fabric Textile 45 Degree Flammability Tester 16cfr 1610 - China

Fabric Textile 45 Degree Flammability Tester 16CFR 1610 Application:

1 - Scope of application:

It is suitable for all kinds of fabrics and their products.

The surface is ignited in the direction of 45 ° to determine the combustion performance of the fabric and the classification of the combustion performance.

2, meet the standards:

2.1 Meet the requirements of GB / T14644-2014 "Determination of Textile Combustion Performance at 45 ° Combustion Rate"; 2.2 Comply with 16CFR 1610-2008 "Standard for the Flammability of Clothing Textiles" standard requirements; 3 - Main performance parameters: 3.1 - Test box: The internal dimensions are: 350mm high, 370mm wide and 220mm deep.

The top 12 vent

holes with a diameter of 12.7mm.

The front is a glass observation window; 3.2 - Test stand: It can support and fix the test stand

so that it is inclined at an angle of 45 °, and can adjust its relative position with the front end of the flame according to the

different thickness of the sample; 3.3 Sample clamp: It consists of two 2.0mm thick U-shaped steel plates, and the inner frame

size is 152mm * 38mm, the sample is fixed in the middle of the two plates, and the two sides are clamped with clamps; 3.4 Burner: Composed of 41/2 gauge syringe needles; 3.5 Gas: butane (chemically pure) 3.6 Marking thread: white cotton mercerized sewing thread (11.7tex * 3) 3.7 Heavy hammer: weight 30kg; 3.8 Timer: 0 ~ 99.99s / m automatic timing; 3.9 Equipped with bristle device;

3.10 Flowmeter: It is a rotor flowmeter; 3.11 Needle valve: adjust the height of the flame; 3.12 Flame measuring scale: measure the flame height of the burner with an accuracy of 1mm; the flame height is 16mm 3.13 Igniter: Automatic ignition for high pressure Our textile testing instruments are sold well in the US, UK, Pakistan, Bangladesh, India and other regions, welcome to order.

QINSUN is a very famous leather & textile testing equipment manufacturer.

Their current achievements in the textile testing industry are extraordinary.

If you have any questions, please consult!

PS: (WLJCDM809)
