China hydrostatic pressure testing equipment The hydrostatic pressure method refers to a test method for measuring the water permeability of fabrics under a certain water pressure.
It is applicable to all types of fabrics, including those that have been waterproofed.
The hydrostatic pressure method measures the waterproofness of fabrics, there are static pressure method and dynamic pressure method.
The static pressure method is to apply hydrostatic pressure on one side of the fabric to measure the amount of water produced under this hydrostatic pressure, the time of dripping, and the value of hydrostatic pressure at a certain amount of water.
The hydrostatic pressure can be high in the water column or It can be pressure.
In the actual measurement, the water permeation per unit area and unit time (mL/cm2 - h) is measured.
For waterproof fabrics, measure the time required for water droplets to appear on the other side of the sample, or observe the number of water droplets on the other side after a certain period of time.
The water resistance of the fabric is related to the water resistance of the fiber, yarn and fabric structure.
The measured results are different from the water spray and rain on the surface of the fabric.
Specific operation: The sample is fixed on the test area of the standard area, the air compressor adds 0-5bar air into a water tank filled with distilled water, and a certain pressure of water is applied to the sample.
It can be tested by dynamic or static two methods.
(1) Dynamic method: Determine the hydrostatic pressure resistance of the sample by testing the pressure when a fixed amount of water drops on the side of the sample that is not in contact with water at a certain pressure increase rate.
(2) Static method: Determine the hydrostatic pressure resistance of the material by testing the water seepage of the sample after maintaining the pressure for a certain period of time under a certain hydrostatic pressure.
- Posted By: Qinsun Instruments (Shanghai) Co., Ltd.
- Phone: +862164200566
- Address: No. 2578 Minhang District Gu Dai Road, Shanghai, Shanghai , shanghai , China
- Website: https://www.qinsun-lab.com
Published date: November 12, 2021
- Business Description: Qinsun Instruments Co., LTD was founded in 2010, comprised of many experienced engineers and designers standing in the forefront of the industry.
Qinsun specialize in the research and development of high quality lab instrument for textile testing industry.
Our head office in Shanghai and we provide high quality testing instrument and comprehensive service for textile factory, academic research institute and textile lab worldwide.
We have our own textile testing lab.
Our textile testing methods and testing equipment are in the leading position in the industry and have passed the textile testing certification and iso textile testing standards issued by a number of testing.
We always develop the highly sophisticated test instrument which can meet the various demands of the textile industry.
We provide the upfront Micro weathering test equipments with our own brand name QINSUN, such as thermal resistance wet resistance meter, MMT(moisture management tester) etc, and the new functional test instrument include air permeability tester, hydrostatic head tester, thermal protection performance tester, as well as the widely used lab testing equipment such as textile washing color fastness tester, abrasion tester, pilling tester, rubbing color fastness tester, ironing tester and perspiration tester.
For the laboratory requirements, we also bring forth the new practical test instruments.
Qinsun products include: fabric test equipment, Textile Fabric Tester, fiber tester, yarn tester, carpet tester, non-woven fabric tester, toy tester, leather tester, automotive material test equipment and others.
