In Motion Tv Antenna For Vehicle And Vessel F Series - China

F-series products are built for watching television programs on the vessels which are sailing in the inland rivers or on the sea.

Our marine antennas offer a variety of programming options for you.

With its advanced navigation attitude system and servo control system, the antenna can always acquire the satellite signal quickly and track the satellite all the time.

Ensure you will not miss your favorite shows just once you are out on an adventure.

Features: - Patented design for max signal strength in an ultra-compact antenna.

- Patented search algorithm and last location recall for faster acquisition.

- Ultra-robust stepper motor for fast channel surfing and signal acquisition.

- Anti power surge and lightning protection design.

Models: F30: Operating Frequency: 10.7~12.75GHz Polarization: Dual Linear/Circular Polar Gain: 30.0dBi@12GHz Min.

EIRP: 50dBW Dimensions: Ø35 X37CM Waterproof Class: IPX6 F45: Operating Frequency: 10.7~12.75GHz Polarization: Dual Linear/Circular Polar Gain: 33.5dBi@12GHz Min.

EIRP: 48dBW Dimensions: Ø51X53CM Waterproof Class: IPX6 F60: Operating Frequency: 10.7~12.75GHz Polarization: Dual Linear/Circular Polar Gain: 34.0dBi@12GHz Min.

EIRP: 46dBW Dimensions: Ø66X68CM Waterproof Class: IPX6 Remark: F-seriels products are customizable now
