Fiber Optic Equipment Fusion Splicer Dvp 740 - China

Specifications of fiber fusion splicer DVP-740

Applicable fibers;

SM, MM, DS, NZ-DS, EDF

Cladding diameter:

100 to 150um

Coating diameter:

100 to 1000um

Fiber cleaved length:

8-22mm (standard)

Splicing mode:

Auto & Manual

Average splice loss:

0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS)

Return loss:

≥ 60dB

Environment conditions:

-25~+50°C (operation temperature), 0~95%RH (humidity), 0~5000m (altitude)

Storage environment:

-40~ +80°C (temperature) , 0~95%RH (humidity)

Protection sleeve length:

20mm , 40mm , 60mm

Tension test:

2.0N (Standard)

Language:

English, Chinese, Korean, Russian, Spanish etc.

Interface:

RS232 interface & video output

Power supply:

AC adaptor: 85~260V input voltage

Internal battery: 12V voltage, 10Ah, more than 200 times of continuous splices and heats

DC adaptor: 12V voltage, optional multipurpose external battery

Dimensions:

142(W)×122(H)×138(D) mm

Weight:

3.3kg
