Full Hydraulic Wireline Core Prospection Drilling Rig Equipment Ky 6075 For Metal Mine - China

1 - The model description of KY-6075 metal mine exploration drilling rig with wire rope

K stands for tunnel.

Y means full hydraulically operated mechanical transmission.

60mm-75mm is the drilling hole diameter.

2 - The applications of KY-6075 metal mine exploration drilling rig with wire rope

The fully hydraulic wireline core drilling rig is suitable for the chamber with complete roof, no broken, no quicksand and no support.

Horizontal drilling: the chamber requires the height is 2000mm and the width is 2000mm.

Horizontal lateral drilling: the chamber requires the height 2000mm and the width is 4000mm.

Vertical upper and lower angle drilling: the chamber requires the height is 4000mm and the width is 2000mm.

3 - The features of KY-6075 metal mine exploration drilling rig

It is small in size, light in weight and easy to install.

The wire line coring can work in all direction and core without pulling out drill pipe.

Three parts: the main engine, the pump station, the operating floor.

It can work in the original transportation and prospecting tunnel, and play a protective role in the overall structure of the mine.

It can also be used for 0-90 degree surface drilling.

The drill rig is arranged with great flexibility, mechanically screwing and unscrewing drill pipe, so it will reduce labour costs and improve work efficiency.

With the box feeding frame, gripper tightening, power head rotary drilling, oil cylinder delivery tool, you can get rid of the heavy drilling tower.

It has the function of linkage, centralized control through operating floor, simple and safe, and no speed regulation.

Hollow shaft design, drill pipe length is not restricted by drilling rig feed stroke.

It is easy to disassemble, and the relocation is convenient.

Three kinds of drilling pipe, Φ49-Φ60-Φ75, can be used on the same machine.

It takes only 15 minutes to replace it.

Compact operating table; oil pump, water pump, power supply centralized .

The drawing column is suitable for the high and low lanes.

The imported oil meter line is subjected to high pressure and its softness will reduce the pressure pulse of high pressure oil, so that it can make the pointer of hydraulic oil table more stable, and can detect the formation and rock changes in time.

The special custom oil temperature cooler, high pressure oil cooling soon and low temperature application can protect the service life of motor, oil pump and rubber seal.
