Servo-Driven Drum Transfer Conveyor – Chain Type

The servo-driven drum transfer conveyor is designed for indexed transportation of steel drum bodies between machines in an automated drum production line.

This conveyor can be integrated with drum body forming, reinforcement, flanging, seaming and leakage testing equipment.

Conveyor length, drum spacing, feeding direction and control sequence are configured according to the customer’s production line.

For other transfer and line-integration options, visit our steel drum conveying equipment category.

♦ Precise Servo Positioning: Powered by a 7.5KW servo motor, it provides accurate stop-and-go motion for consistent positioning at each workstation.

♦ High-Capacity Chain Drive: Designed to handle standard 571.5mm diameter drums at a line speed of 3-4 units per minute.

♦ Robust Construction & Reliable Components: Built with quality Chint​ electrical components and Airtac​ pneumatic parts for durability in industrial environments.

What the Servo Drum Transfer Conveyor Does

A steel drum body production line normally contains several machines that operate in individual cycles.

These may include rolling, welding, beading, corrugation, flanging, seaming and leak testing equipment.

The conveyor transfers the drum body from one station to the next while coordinating its movement with the processing cycle.

Its main functions include:

♦ Receiving a drum body from the upstream machine

♦ Maintaining controlled spacing between consecutive drums

♦ Moving the drum toward the next production station

♦ Stopping the drum at the required processing position

♦ Waiting for the downstream machine to complete its cycle

♦ Restarting the transfer after receiving the next operating signal

♦ Supporting continuous coordination of multiple drum-making machines

The exact transfer sequence depends on the connected equipment and the automation level of the complete production line.

Chain-Driven Conveyor Structure

Compared with manually pushing drum bodies between separate machines, the chain type drum transfer conveyor provides a fixed transfer path and coordinated movement.

It is particularly suitable for connecting production stations that require drums to enter in sequence.

The chain conveyor configuration can be designed according to:

♦ Drum diameter and height

♦ Drum body weight at the relevant process stage

♦ Required transfer distance

♦ Number of connected machines

♦ Production speed

♦ Machine center height

♦ Feeding and discharge direction

♦ Workshop floor conditions

♦ Required maintenance access

Final chain structure and support arrangement should be confirmed during technical design.
