Cnc Electric Spark Wire Cutting Machine - China
price: contact company for price
CNC Electric Spark Wire Cutting Machine
CNC Cutting Machine Tool
Type unit DK7740F DK7750 DK7750B DK7750F DK7763 DK7763F
Worktable Size (W*L) mm 48020 56404 61550 594064 700060 700200
X, Y-axis tripY mm 40030 50030 55090 50000 63000 630000
U, V-axis tripU mm 700
Max load weight kg 700 800 900 1000 1100 1300
Max linear cutting thickness of Super Machine Tool mm 500mm430 600mm530 600mm530 600mm530 600mm530 600mm530
Machined taper/work piece thickness 12/80mm
Z-axis elevation mode Manual/electric elevation
Type of guide track Slide guide
Electrode wire diameter range mm Ф0.15~0.20mm
Wire speed m/sec 1~11.4m/sec 7frequency conversion adjustable
Machining accuracy mm ≤0.015
Max cutting efficiency of CNC Machine Tool mm/min ≥120
Optimum surface roughness um Ra≤2.5
Control mode X, Y, U, Vstepper motor
Number of control axis Four-axis linkage
Min instruction unit mm 0.001
Power supply of CNC machine tool control system Three-phase four-wire 380VAC/50HZ
Max operating current A 12
Machine tool power consumption kw 2
Working fluid DX-1 DX-4 Nanguang-1
Working fluid tank volume L 55
Work liquid filtrate way Strainer
Host weight kg 1500 1900 2000 2100 2600 2800
Host outline size mm 2100500400 2100700740 2150800740 2400800740 2400250650 2400400650
More information can view Hifactory.
Company Contact:
- Posted By: Taizhou Wenjie CNC Equipment Co., Ltd.
- Phone: 15896004996
- Address: No.28 Xingling road, Hailing industrial park, Taizhou , Jiangsu province, China
- Email:
- Website: https://www.wjcncmachine.com
Published date: November 14, 2019
- Business Description: Taizhou Wenjie CNC Equipment Co., Ltd., formerly known as Taizhou Hailing District Zhongxing CNC Machine Tool Factory, an established enterprise specialized in the creation of CNC linear cutting machines, is located in Taizhou, Jiangsu, where is known as the hometown of Mei Lanfang, master of Peking Opera.
Situated in Hailing Industrial Park, Taizhou, it is a vice president company of Taizhou Special Processing Machine Association and a high-tech enterprise in Taizhou, integrating R&D, creation, operation and sales.
