Mjsf 280oe Oil Electrical Heating Exchange Singles Facer - China

※Structural features:

★Design speed: 100m/min

★Effective width: 1000mm ~ 2500mm

★Using suction hood structure, with a strong high pressure blower, suction with a silencer.

Gas supply and electrical control centralized in the same operation panel, not less than 1.5 meters from the hosts, operating side cover closed.

★Cast iron wallboard, siding thickness of 130mm.

Universal Joints.

★Corrugated roller material adopt 48CrMo alloy steel, after quenching, intermediate frequency quenching, surface polishing, corrugated main roller diameter¢ 280mm, surface hardness more than HRC58 degrees, airbag loading.

The key parts of the tile and pressure roller bearings high temperature bearings Wafangdian production.

★Corrugated roller, pressure roller materials provided by the Central Plains Steel, corrugating unilateral 0.15mm high, the pressure roller unilateral 0.075mm high.

★preheat roller with Day steel production seamless Steel Tube¢ 320mm.

★Using four sets of electric heating pipe heating oil, heating fast, no furnace, automatic temperature control and two groups control.
