High Precision Stainless Steel Speed Auto Sensor Punching Machine - China

Patent NO.

ZL201420117093.1

Model：KS-CPM-AH01


Specifications：

Power：10.0KW

Power Source：AC380V/50Hz

Air Pressure：0.6 Mpa

Punching Accuracy：±0.1mm.

Material：PVC, ABS, PET or Mixed material

Material Size：length range：400mm -480mm, width range：282mm-452mm

Capacity：900~1100 sheets/hour

Weight：1500Kg

Dimension：(L)2200mm X (W)2600mm X(H)1800mm

Applying Area

This machine is used for punching ISO standard cards or NON-ISO standard cards.

It applies the vision system to make the position and the sorting function.

It could save manpower cost.

Features: 1 - Feeding unit: Auto feeding, applying the lift chain system, it could ensure every sheet feeding even and stably.

2 - Position Unit: applying high sensitive sensors to make the position very accurately.

3 - Transfer unit: Applying the high accuracy guide screw to make the materail running stably and accurately.

4 - Punching unit：Using the PLC to control the punching system to make the punching stably and low noise.

The punching accuracy reaches ±0.1mm.

And it also could work well with lamination deform card to reduce the NG rate.

5 - Sorting Unit: the machine could place the same position cards into the same output box, it could save the manpower to sort the cards.

6 - Output Unit: the output boxes could be designed from 1 box to 64 boxes depends on the client's request.

It could solve the sorting problem with mixed cards.

7 - Control Unit: applying the touch screen to control, it is easy and fast to operate.

Company Contact:

• Posted By: Shenzhen King Science Automation Equipment Co., Ltd.

• Phone: +86-755-27628362

• Address: 1st Floor, Building 11, Sanlian Industrial Zone, Shiyan, Bao’an District, Shenzhen, Guangdong, China, Shenzhen , Guangdong , China

• Email:

• Website: http://www.king-science.com

• Business Description: Contact person: Mr.

  Cheng

  Phone: +86 15814013058

  Shenzhen King Science Automation Equipment Co., Ltd. is found at 2007 - which has the design, manufacture, sales and service team and it is a high-tech company.

  The main business is digital personalization machines, poker/game card machines, business cards/tags machines, RFID products machines, smart cards/IOT machines, and also specialized on different kinds of punching tools research and manufacturing.

  We have released the Auto High Speed Vision Position Punching Sorting Machine in 2014, released the smart card collation, cleaning, overlay, magstripe functions machine in 2015 - Our company has many years experience professional team which could design the machines according to clients' requirements and we are in the lead position in the industry.



  Our machines have been approved by domestic and oversea customers.

  We have dozens of independent property rights, and many patents.

  Our company got the Shenzhen High Tech Enterprise on April 1, 2014, and got the National High Tech Enterprise on June 19, 2015 - "Accuracy, Fast, Stable, Long Term" are King Science purposes.

  Saving the clients' cost, improving the capacity are King Science's base stone.
