1 - The product definition

Compressed air precision filter is to remove the pollutants in the compressed air system, such as corrosion solid particles such as dust, scrap iron and fouling, the compressor lubricant, condensation water and acid cold condensate oil and hydrocarbon steam fog, etc., for the air compressor system to provide the high quality of compressed air meets the application requirements.

Main composition: filter, filter shell, end cover, teeth, etc.

;

Filter material selection and the general connection of process piping material is the same, for different service conditions can consider to choose cast iron, carbon steel, low alloy steel or stainless steel filter.

2 - The product features

1, high efficiency to remove water, oil mist, solid particles, 100% removal of 0.01 microns or more particles, oil mist concentration control in the 0.01 PPM/wt; 2, reasonable structure, small volume, light weight; 3, with cover plastic shell and aluminum alloy shell can choose.

4, section purification treatment, long service life

Compressed air precision filter in order to achieve high precision quality, used the filter layers of different materials, which contains boron silicate fiber, glass fiber layer, layer of activated carbon fiber, multi-layer nonwoven fabric layer and stainless steel wire mesh.

The only way to achieve no oil, no impurity of high quality air.

3 - The filter selection principles

1, import and export size: in principle, the import and export of the filter size should not be less than the import of matching pump size, generally consistent with imported pipe diameter.

2, working pressure, determined in accordance with the highest pressure filter line possible filter pressure rating.

3, level of filtering: main consideration to intercept impurities particle size, according to the medium flow process requirement.

All kinds of wire mesh can intercept the particle size of the check table below "mesh specifications".

4, air capacity: according to the working pressure is 0.7 to 1.0 Mpa large air capacity.

5, filter material: filter material selection and the general connection of process piping material is the same, for different service conditions can consider to choose cast iron, carbon steel, low alloy steel or stainless steel filter.

4 - Precision filter cores fine points

C at passing filter can remove a large amount of liquid and 3 microns above solid particles, only 5 PPM, meet minimum residual oil content with a small amount of moisture, dust and oil mist.

Used for air compressor, the back of the cooler, after before other filters, for general protection;Pretreatment device used in person before.

T air line filter Can filter out as small as 1 mu m liquid and solid particles, minimum residual oil content reached 0.5 PPM, trace moisture, dust and oil mist.

For class A filter used for pretreatment before;Person and blot machine, to further improve air quality.

A super-efficient oil removal filter can filter the liquid and solid particles as small as 0.01 microns, minimum residual oil content reached 0.001 PPM, almost all the moisture, dust and oil has been removed.

Used for filtering and blot machine before class H protection, after the person, make sure no oil in the air.

H activated carbon filter can filter out as small as 0.01 microns of oil mist and hydrocarbons, minimum residual oil content reached 0.003 PPM, contains no moisture, dust and oil, odourless tasteless.

A final filtration effect for some must use high quality high quality air units, such as the food industry, breathing, aseptic packaging, etc.
