Foxboro Fbm242 Output Module - China

The FBM242 Discrete Output Module contains 16 discrete output channels, which are sourced externally, rated up to 2 A at 60 V dc.

Associated termination assemblies (TAs) provide for discrete outputs to loads of 2 A at 60 V dc, relay outputs (120 V ac/125 V dc, or 240 V ac), or relay outputs with power distribution and fusing.

Each output is fully isolated from other channels and ground.

The module interfaces electrical output signals from a control processor to the field devices.

It executes a digital I/O application program, with ladder logic support, and provides a Fail-Safe Configuration option for the outputs.

FEATURES Key features of the FBM242 modules are:  Sixteen discrete outputs  Supports discrete output signals at voltages of: • 15 to 60 V dc • 120 V ac/125 V dc • 240 V ac  Each input and output is galvanically isolated; group isolated when used with external excitation  Rugged design suitable for enclosure in Class G3 (harsh) environments  Executes the Discrete I/O or Ladder Logic program, with the following configurable options: Input Filter Time, Fail Safe Configuration, Fail-Safe Fall-Back, and Sustained or Momentary Outputs  Various Termination Assemblies (TAs) that contain: • Current limiting devices • Fuses • Relay outputs with external power source, fusing, and power distribution • Solid state outputs • Redundant power distribution.
