Dirp Coffee Bag Packing Machine With Outer Envelope - China

1) Automatic multi-function packaging forming machine;

2) Suitable for coffee powder/ground coffee;

3) Inner drip bag is by heat sealing;

4) Food grade filter paper drip bag; with outer envelope;

5) High quality with PLC controller and PID temperature controller;

6) All-round process: filing, weighting, bag forming, sealing, cutting and counting etc.

7) Reserved connector for nitrogen flushing.

8) Quality certificated : CE, ISO9001: 2008

9) Manufacturing experience : twelve years

Application:

It is suitable for packing 5 to 15gram ground coffee powder in drip coffee bag with outer envelop, such as Blue Mountain

coffee, Brazil coffee, Italian Espresso, Kenya coffee, Columbia coffee, Hawaii Kano Coffee, Mocha Coffee etc.

Machine Features:

1 - Outer bag sealing is controlled by the stepper motor, ensuring accurate and stable bag length positioning.

2 - Adopts PID temperature controller for more accurate temperature adjustment.

3 - Adopts PLC control system and touch screen color monitor device, machine is very easy to operate.

4 - The main machine parts, especially material touching parts, are made of SUS304 stainless steel, so it ensures hygiene

products output.

5 - Some cylinders are imported, ensuring the accuracy and stability of the machines’ performance.

6 - It can make the inner and outer bag at the same time automatically, which would highly improve the working efficiency.

7 - Adopts automatic conveyor system.

8 - Options: Date code printer.

Standard Technical Data:

Machine type: Drip Coffee Packaging Machine Series

Machine model: C19II

Machine name: Automatic Drip Coffee Bag Packing Machine with Outer Envelope

Sealing method: Three sides sealing

Packing material: Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper

Feeding system: Measuring cup filler

Package range: 5-15g

Inner bag size: L: 50-75mm, W: 50-90mm

Outer bag size: L: 85-120mm, W: 75-100mm

Inner bag film width (180mm): Bag size: L90mm*W75mm

Outer bag film width(200mm): Bag size: L120mm*W100mm

Power supply: Single phase, 220V, 50HZ, 3.7KW

Packing speed: 30-60bags/min

Machine weight: 400KGS

Machine dimension: 1200*900*1900mm(L*W*H)

Company Contact:

• Posted By: Xiamen Sengong Packing Equipment Co., Ltd

• Phone: 05925523433

• Address: No.228, Tianfeng Road, North Industrial Zone, Jimei District, Xiamen , Fujian , China

• Email:

• Website: https://www.simplerpack.com

• Business Description: Xiamen Sengong Packing Equipment Co., Ltd is a professional manufacturer of automatic vertical packaging

  machinery with more than ten years experience in machine development, research, design, production and service.

  In

  2004, the first "Horizontal In-feeding Label" inner and outer bag packing machine was produced in our company,

  which opened up a new era of inner and outer bag tea packaging machine in China.

  Our main products include inner and outer bag tea packaging machine, ground coffee packaging machine, powder

  packaging machine, liquid packaging machine and others packaging machine for special materials, etc.

  High quality,

  efficient and stable, safe and environmentally friendly, energy saving, the machines are widely used in tea, medicine,

  food, chemicals, hardware, electronics and other industries.

  The market share of the "Horizontal In-feeding Label" inner and outer bag packing machine ranks the first in the

  domestic market among similar industries.

  With decades of unremitting efforts, we have developed a series of more

  flexible, more stable and more user-friendly packaging machines, which better meet the requirements of different

  customers ind different industries.

  Even more, the machines have been exported to the United States, Canada, Russia,

  Ukraine, Italy, Australia, Malaysia, Saudi Arabia, Turkey, Brazil and so on.

  Besides, we have a perfect after-sales service guarantee system.

  Staffed with experienced technicians, engineers and

  managerial personals, "quality, rapid and efficient" service from our aster-sales service department are provided for all

  customers.
