Continous Carbonization Furnace - China

Continuous Carbonization Furnace is a new type of environmentally friendly carbonization equipment.

The biomass material is converted to charcoal after passing through a carbonization stove and can be further processed.

Compared with other carbonization equipment, this carbonization furnace for briquette can work continuously for 24 hours to achieve high output, so it is called continuous carbonization furnace.

The entire production process does not produce harmful gases, does not pollute the environment, and is excellent in various carbonization furnaces.

Acceptable Biomass for Continuous Carbonization Furnace

Continous Carbonization Furnace is mainly used for all kinds of biomass material: Fruit Husk, Wood Scraps, Sugarcane Bagasse, Crop Stalks, Rice husk, Coconut shell, Peanut shell, Groundnut shell, Sunflower seed husk, shell, Palm kernel shell, Walnut shell, Almond shell and Pistachio shell etc.

Meanwhile, electronic waste, cans, waste wires, sludge, household garbage and other materials with biomass properties can also be used as raw materials for continuous carbonization furnaces (size less than 20mm, moisture less than 15%) How to use Continous Carbonization Furnace

The entire carbonization process mainly includes crushing, drying, feeding, carbonization, discharging, combustible gas recovery, exhaust gas treatment, and briquette production.

01 Preprocessing

Crushing (optional): The crushing system processes raw material into target sizes (less than 20mm).

Drying (optional): The drying system processes the raw material to a moisture content of less than 15%.

02 Carbonization

Feeding: Raw biomass (sawdust, wood chip, crushed coconut shell etc) is automatically fed into the furnace via a conveyor belt, screw feeder or Z-Belt.

Carbonization: After heating the main furnace, the temperature gradually rises.

The initial temperature helps dry out some of the moisture in the raw material.

When the temperature reaches 250 degrees Celsius, demethylation begins.

Combustible gas starts to generate.

At 280 degrees Celsius, the exothermic reaction begins.

The hydrocarbon molecules split into smaller carbon molecules and hydrogen.

charcoal begins to be produced.

As the temperature hits 450 degrees Celsius, aromatic ring compounds begin reacting.

3 Discharging

Charcoal: Through a three-stage water-cooling discharger, charcoal below 45 degrees Celsius is collected.

Tar & wood vinegar collection (optional): Via the condenser, tar (biomass oil) and wood vinegar separate out and are collected separately.

Charcoal briquette making (optional): After being processed by the charcoal briquette machine, the original shape of charcoal can be made into the required shape, such as round, square, stick, etc.

04 Combustible Gas Recovery

After condensation and sulfur removal treatment, combustible gas can be recovered and reused.

We can also introduce the excess heat from the carbonization furnace into the dryer to recycle the combustible gas, thereby saving fuel for the dryer.

05 Exhaust Gas Treatment

The emission gas is treated by a spray tower, water curtain de-dusting tower, and cooling tower.

The processed emission gas meets the EU emission standards.

Weiwa Group provides high-standard customized exhaust gas treatment system.

Features of Continuous Carbonization Furnace Equipped with Alarm Device

The PLC electric cabinet has an alarm device, and there will be an alarm display and an alarm for some electrical failures.

With Explosion-proof Water Seal

There is an explosion-proof water seal at the combustible pipeline (to prevent abnormal pressure of combustible gas in the equipment).

Variable Frequency Fan Guide

The direction of the gas in all pipelines is led by the fan (the fan is variable frequency), and it will be displayed on the PLC when the pipeline is blocked.

High Heat Efficiency

The material is not in contact with the flue gas and is not polluted by hot air.

Good Energy-saving Effect

The heat utilization rate of this equipment is higher, the use of air heat ex-changer can effectively improve the thermal efficiency by 5-10%, and the energy saving effect is good.

Learn More about the Properties of Biochar

Biochar is a carbon-containing substance formed by carbonization of biomass (such as wood, agricultural waste and other plant residues).

Biochar production equipment ensures pyrolysis reaction takes place under high temperature and oxygen-free conditions.
