Oil Rig Mud System Linear Motion Shale Shaker - China

price: contact company for price

Oil Rig Mud System Linear Motion Shale Shaker

Products Photos Catalog Oil Rig Mud Linear Photos Catalog

Shale Shaker-Linear&Ellipti cal Motion

Shale Shaker, to some extent, to be knowned as the first and vital phase during the procedure of separation in Oil&Gas Drilling, Civil Construction or other challenging industries involved.

Shale Shaker KES produced, the most advanced model KAZTS114-AHB, offering optional Linear and Elliptical Motion, with cost-effective solutions plus award-winning service, the KES shale shaker is the latest in a long line of products designed expressly to exceed the demanding needs of today’s Oilfield drilling operations.

Shale Shaker, so with its compact footprint, industry-leading processing capacity, solids bypass prevention, and low maintenance cost, the KES shale shaker is suitable for all drilling applications where drilling performance and rig modularity are required.

It is designed to bring maximum value to all clients.

Shale Shaker, besides the KAZTS114-AHB series, we also offer you common Linear Motion shale shaker, and our specialist will you suggestions to solve your problems.

SHALE SHAKER(Dr.

Mark 86017603164653)

Model KAZS112-QDZ KAZS113-AHB KAZS114-AHB KAZS114-ALD KAZTS114-AHB

Vibration Mode Linear Motion

Treatment Capacity(m³/h) 70 120 150 150 150

Motor(kw) 2x0.75 2x1.72 2x1.94 2x1.94 2x1.94+0.4

Screen Qty 2 3 4 4 4

Screen Size(mm) 750x900 585x1165 585x1165 585x1165 585x1165

Screen Area(m²) 1.35 2.04 2.73 2.73 2.73

Output Force(G) ≤7.1 ≤7.5 ≤8.0 ≤8.0 ≤8.0

Double Amplitude(mm) 3.92-5.62 4.14-5.96 4.4-6.34 4.4-6.34 4.4-6.34

Deck Adjustment +2° -3-+3° -3-+3° -3-+3° -3-+3°

Weir Height(mm) 550 885 885 885 885

Explosion-proof ExdllBt4/IECEX/A-TEX

Weight(kg) 837 1365 1553 1520 1633

Dimensions(mm) 1940x1360x970 2322x1650x1400 2912x1650x1425 2650x1650x1425 2912x1650x1425


Company Contact:


  • Phone: 08617603164653

  • Address: Industry 2nd Road,Chaobaihe Industrial, Langfang , Hebei , China

  • Email: Email


Published date: May 31, 2019

  • Business Description: pioneering manufacturing factory with exponential growth.

    Formally we are in good position to offer you leading-edge solutions for entire line of separation technology, involving in Oil&Gas Drilling, Civil Construction, industrial and other challenging industries worldwide.
